MB063FG
Universal, Industrial, Household Appliances, Car, Power Tools
Low Speed
Brush
63mm
0.6A
Exmek
Cartor and Wood Pallet
CE, RoHS
China
85013100
Product Description
Feathered:
Voltage: 12-72V,
CE / RoHS appliance.
Rated Speed: 3000-5000Rpm.
Rated Torque: 0.1 - 0.7Nm.
Max output power up to 140W
Stable speed-torque characteristics
Internal Brush Construction
Provide custom design. Welcome to contact.
Voltage: 12-72V,
CE / RoHS appliance.
Rated Speed: 3000-5000Rpm.
Rated Torque: 0.1 - 0.7Nm.
Max output power up to 140W
Stable speed-torque characteristics
Internal Brush Construction
Dimension Drawing of MB063FG Series
Provide custom design. Welcome to contact.
| Part No | No load | Ke (V/Krpm) | Rated | Peak Torque (N.m) | ||||
| Speed (rpm) | Current (A) | Voltage | Speed (rpm) | Torque (N.cm) | Current(A) | |||
| MB063FG138 | 4174 | 0.34 | 6.0 | 24 | 3100 | 14 | 2.6 | 0.576 |
| MB063FG210 | 3288 | 0.64 | 7.0 | 24 | 3000 | 9.76 | 2.08 | 0.882 |
| MB063FG301 | 3377 | 1.127 | 6.6 | 24 | 3500 | 12 | 2.9 | 0.475 |
| MB063FG501 | 3349 | 0.869 | 6.7 | 24 | 3000 | 20 | 3.8 | 0.99 |
| MB063FG521 | 3817 | 0.54 | 6.4 | 24 | 3000 | 32 | 5.86 | 1.5 |
| MB063FG527 | 3672 | 1.446 | 3.1 | 12 | 3000 | 29 | 10.3 | 0.92 |
