ME080AS100
Universal, Industrial, Household Appliances, Car, Power Tools
Adjust Speed
Excited
Control
Closed Type
8
Brushless
ISO9001, Ce
Exmek
Exmek
CTN & Pallet
CE, RoHS
China
8501310000
Product Description
General information
Specifications
Company Capabilities
- 8 poles with three phase
- 15 slots distribution winding design for low cogging
- 6 slots for automatic winding
- Insulation class B, higher insulation class on request
- Sintered Neo Magnet
- Multiple lines of encoder available
- Lower voltage available
Specifications
| Specification | ME080AS100 |
| Supply voltage(reference) | 310 ( VDC) |
| Rated continuous torque | 1 (Nm) |
| Rated speed at cont. Torque | 3000 (rpm) |
| Rated continuous stall current | 1.87 (A) |
| Rated continuous output power | 316 (W) |
| Rated peak torque | 3.04 (Nm) |
| Rated peak current | 4.73 (A) |
| Torque constant | 0.7033 (Nm/A) |
| Ke(voltage constant) | 73.61(V/krpm) |
| Terminal resistance | 13 (Ω) |
| Inductance | 65 (mH) |
| Insulation class | B |
| Rotor inertia | 6.00E-05 (Kg. M²) |
| Weight | 1.8 (Kg) |
| Length | 111 (mm) |
Mechanical
Characteristic diagram
Packaging & Shipping
1, Waterproof plastic bag packed in foam box and carton as outer packing.
2, Export wooden box packaging for products.
Company Profile
- Originally motor division of CMEC WUXI- China National Machinery & Equipment Imp & Exp Wuxi Co., Ltd., one of TOP 20 stated owned Machinery Group
- Privately owned Ltd company since 2000: Wuxi Junhong Automation Technology Co. Ltd.
- Exmek Electric ---Registered Brand Name
- Business: Design and manufacture of motion control products and components
- Highly qualified personnel
- UL, CE, RoHS certification
- ISO 9001, ISO 14000
Company Capabilities
- Modern Motor Design and Manufacture
- Part Set Design and Manufacture
- Magnetic Design Software-Motorsolver
- Molding
- Shipping world wide
- Open for general discussion and questions
- Time to market or theatre of operations can be substantially reduced
- Talented team of engineers providing innovative technical solutions
- One stop "supplier" and complete sub-system
- Quality products provided at competitive low cost
- Ability to ship world wide
- On time delivery
- Training at Customer locations
- Fast service on return and repair results
- Many repeated customers
Applications:
Use for swimming pool, automotive, semiconductor, chemical & medical, industrial automation, power tool, instrument, measuring equipment, office automation, various OEM application.
