BLDC Brushless DC Motor Series 57BL NEMA23
Brushless DC Motor :
The BLDC motor offers exceptional torque and speed, higher efficiency, as well as package sizes suited to meet the most stringent of application requirements. These brushless DC motors are electronically commutated and can be supplied in either sensored or sensorless versions, with all having 3 phase windings. Be it Round, Square or Flat, these products offers the following benefits:
1) Winding Type: Star
2) Hall effect angle: 120°Electrical angle
3) Insulation Class: B
4) Ambient Temperature: -20ºC~+50ºC
5) Insulation Resistance: 100MΩ Min.500V DC
6) Dielectric Strength: 600VAC 1 minute
7) Max Radial Force: 75N (10mm from front flange)
8) Max Axial Force: 15N
1) Winding Type: Star
2) Hall effect angle: 120°Electrical angle
3) Insulation Class: B
4) Ambient Temperature: -20ºC~+50ºC
5) Insulation Resistance: 100MΩ Min.500V DC
6) Dielectric Strength: 600VAC 1 minute
7) Max Radial Force: 75N (10mm from front flange)
8) Max Axial Force: 15N
Brushless DC Motor Series 57BLY
The 57BLY Brushless DC motor is a synchronous electric motor which is powered by direct-current electricity (DC) and which has an electronically controlled commutation system, instead of a mechanical commutation system based on brushes. In such motors, current and torque, voltage and rpm are linearly.
Motor Highlights
- Round shape
- 3 phases
- Hall sensors
- 4 poles, Bonded NdFeB Magnets
- Rated torque up to 440 mNm
Specifications of Brushless DC Motor Series 57BL NEMA23
| Model | Rated voltage | Rated output power | Rated speed | Rated current | Rated torque | Peak current | Peak torque | Voltage constant | Torque constant | Number of poles | Winding class | Motor Length | Motor weight |
| U | Pout | nN | IN | TN | IP | TP | KE | KT | NP | L | |||
| V | W | rpm | A | N.m | A | N.m | V/ Krpm | N.m/A | mm | Kg | |||
| 57BLY01-2430 | 24 | 15 | 2500 | 0.77 | 0.057 | 2.31 | 0.17 | 7.75 | 0.074 | 4 | B | 41.5 | 0.35 |
| 57BLY02-2438 | 24 | 34 | 3000 | 1.84 | 0.11 | 5.5 | 0.33 | 6.28 | 0.06 | 4 | B | 46.5 | 0.44 |
| 57BLY03-2438 | 24 | 52 | 3000 | 2.75 | 0.165 | 8.25 | 0.5 | 6.28 | 0.06 | 4 | B | 56.5 | 0.56 |
| 57BLY04-2438 | 24 | 69 | 3000 | 3.67 | 0.22 | 11 | 0.66 | 6.28 | 0.06 | 4 | B | 66.5 | 0.67 |
| 57BLY05-2438 | 24 | 104 | 3000 | 5.5 | 0.33 | 16.5 | 0.99 | 6.28 | 0.06 | 4 | B | 86.5 | 0.95 |
| 57BLY06-2438 | 24 | 138 | 3000 | 7.33 | 0.44 | 22 | 1.32 | 6.28 | 0.06 | 4 | B | 106.5 | 1.18 |
| 57BLY3A50-2438* | 24 | 63 | 3000 | 3.3 | 0.2 | 9.9 | 0.6 | 6.28 | 0.06 | 4 | B | 50 | 0.6 |
| 57BLY3A70-2438* | 24 | 126 | 3000 | 6.6 | 0.4 | 19.8 | 1.2 | 6.28 | 0.06 | 4 | B | 70 | 0.85 |
| 57BLY3A90-2438* | 24 | 189 | 3000 | 9.9 | 0.6 | 29.7 | 1.8 | 6.28 | 0.06 | 4 | B | 90 | 1.1 |
Remark:
1. This motor can be customized with special request.
2. Options: Planetary gearhead 56mm; Round and square front flanges; Encoder; Brake.
3. Sintered magnet.
| ELECTRICAL CONNECTION TABLE | ||
| FUNCTION | COLOR | WIRE GAGE |
| +5V | RED | UL1007 26AWG |
| HALL A | YELLOW | |
| HALL B | GREEN | |
| HALL C | BLUE | |
| GND | BLACK | |
| PHASE A | YELLOW | UL1015 20AWG |
| PHASE B | GREEN | |
| PHASE C | BLUE | |
