57HS2a56-156 Stepping Motor
Printing Equipment
Low Speed
Two-Phase
HB-Hybrid
Driving
2
The Three Single Phase
Hybrid
ISO9001, CCC, SGS
Sunrise Motor
90
1.5
SUNRISE MOTOR
Carton, Pallet
57hs2A56-156
China
85011099
Product Description
Product Description
Model:57HS2A56-156
Holding Torque:90N.cm
Current:1.5A
Resistance:3.2Ω
Motor Length:56MM
Weight:590g
Motor are available with different winding and mechanical modification to meet specific applications.
Model:57HS2A56-156
Holding Torque:90N.cm
Current:1.5A
Resistance:3.2Ω
Motor Length:56MM
Weight:590g
Motor are available with different winding and mechanical modification to meet specific applications.
| Model | Holding Torque (N·cm±10%) | Current/Phase(A) | Resistance/Phase (ohms±10%) | Inductance/Phase (mH±20%) | Detent Torque (N·cm) | Rotor Inertia (g-cm 2 ) | Length (mm) | Weight (g) |
| 57HS2A56-156 | 90 | 1.5 | 3.2 | 5.5 | 3.5 | 280 | 56 | 590 |
| 57HS2A56-254 | 110 | 2.5 | 1.3 | 4.2 | 3.5 | 280 | 56 | 680 |
| 57HS2A56-304 | 110 | 3.0 | 0.8 | 2.4 | 3.5 | 280 | 56 | 680 |
| 57HS2A56-424 | 110 | 4.2 | 0.4 | 1.2 | 3.5 | 280 | 56 | 680 |
