CPCD15-XW33C-RT4, CPCD18-XW33C-RT4
Not Adjustable
Diesel Forklift
Diesel Engine
1.5-1.8ton
Diesel
500mm
3000-6000mm
New
Rough Terrian Forklift
HANGCHA
Exporing Packing
As per model
China
8427209000
Product Description
Hangcha 2WD/4WD Rough Terrain Forklift with capacities of 1,500 to 1,800kg
Hangcha 1.5~1.8t 2WD/4WD rough terrain forklifts is a tough, compact forklift. It is world renowned for superior performance, economy and longevity.
Overview:
The multipurpose concept refers to the capability of the forklift truck to work in many different areas, with a great performance no matter how hard the conditions are. We studied all the specifications of the best forklifts in the world, specialized in industrial and rough terrain types, determining the characteristics that makes a forklift work well in an industrial environment. After that, we combined such information, to prepare the basis of the design of our product.
Standard specification
/Suspension transmission
/Dierential lock
/2-wheel drive,4-wheel drive system
/Suspension seat
/Return oil filter
/Big capacity aluminum radiator
/Air filter
/Rear working light
/Warning lamp
/Cover for tilt cylinder
/Reversing assist grip
/Wider fork carriage
/Wider load backrest
/LED light
/Dierential lock
/2-wheel drive,4-wheel drive system
/Suspension seat
/Return oil filter
/Big capacity aluminum radiator
/Air filter
/Rear working light
/Warning lamp
/Cover for tilt cylinder
/Reversing assist grip
/Wider fork carriage
/Wider load backrest
/LED light
Options
/Cabin
/Heater
/Front window
/L/R mirror
/Extinguisher
/OPS system
/Sparkle arrester
/Purified exhaust system
/Auxiliary hydraulic valve
/Front working light
/Triplex wide view free-lift mast
/Special forks
/Weigher system
/Net cover of radiator
/Heater
/Front window
/L/R mirror
/Extinguisher
/OPS system
/Sparkle arrester
/Purified exhaust system
/Auxiliary hydraulic valve
/Front working light
/Triplex wide view free-lift mast
/Special forks
/Weigher system
/Net cover of radiator
No. | Item | |||
1 | Model | CPCD15-XW97E-RT2 CPCD15-XW33E-RT2 CPCD15-XW97C-RT4 CPCD15-XW33C-RT4 | CPCD18-XW97E-RT2 CPCD18-XW33E-RT2 CPCD18-XW97C-RT4 CPCD18-XW33C-RT4 | |
2 | Engine | YANMAR 4TNE98 KUBOTA V2607-CR-E5B | YANMAR 4TNE98 KUBOTA V2607-CR-E5B | |
3 | Power type | diesel | diesel | |
4 | Rated capacity | kg | 1500 | 1800 |
5 | Load center | mm | 500 | 500 |
6 | Self-weight | kg | 3800 | 3950 |
7 | Tire size, front | 12-16.5 | 12-16.5 | |
8 | Tire size, rear | 27×10-12 | 27×10-12 | |
9 | Height, mast lowered | mm | 2165 | 2165 |
10 | Lifting height | mm | 3000 | 3000 |
11 | Length to face of forks | mm | 3050 | 3050 |
12 | Overall width | mm | 1450 | 1450 |
13 | Fork size(s/e/l) | mm | 35×100×1070 | 35×100×1070 |
14 | Turning radius | mm | 2800 | 2800 |
