Bale Clamp
1 Year
1 Year
Steel
Painting
Customized
Standard
Forklift Attachments Bale Clamp
Bale Clamp
Forklift Attachments
VSM
Export Standard Packing
As per model
China
8431209000
Product Description
VSM is a professional exporter and manufacturer of Warehouse Equipments, Forklift, and Forklift attachments.
Pallet truck, pallet stacker, reach truck...;
Diesel forklift, LPG/Gasoline forklift, Battery forklift...;
Side shifter, Fork positioner, Paper roll clamp, Bale clamp,Block clamp, Rotator, Drum clamp, Push & Pull, Tilt bucket, Fork extensioner and all other forklift attachments;
Pallet truck, pallet stacker, reach truck...;
Diesel forklift, LPG/Gasoline forklift, Battery forklift...;
Side shifter, Fork positioner, Paper roll clamp, Bale clamp,Block clamp, Rotator, Drum clamp, Push & Pull, Tilt bucket, Fork extensioner and all other forklift attachments;
Bale clamp applies efficiently and economically handling, stacking or rotating nearly any type of baled products including cotton wool, synthetic, textile bales, corrugated, newsprint, rag, hay metal and other scrap bales in palletless operation condition. Commonly equipped in industries as paper mill material recycling, railway transportation, logistic warehouse, port, textile and related.
Key specifications for forklift bale clamp:
1. forklift brand and loading capacity
2. diameter of bale
3. weight of bale
4. better if provide photos of bale
Key specifications for forklift bale clamp:
1. forklift brand and loading capacity
2. diameter of bale
3. weight of bale
4. better if provide photos of bale
Bale clamp main specifications:
| NO. | Forklift | Model | Rated loading capacity (kg/mm) | Valve | opening range (mm) | Overall frame width (mm) | Effective thickness | Horizontal center of gravity (mm) | Mounting class |
| 1 | 2T 2.5T | ES9B-BCS-122A-J | 2500/500 | 4 | 550- 1880 | 1038 | 170 | 390 | II |
| 2 | 2T 2.5T | ES9B-BCS-302A-J | 2500/500 | 4 | 460- 2060 | 1408 | 170 | 390 | II |
| 3 | 3T 3.5T | ES9B-BCS-122B-J | 2500/500 | 4 | 550- 1880 | 1038 | 170 | 390 | III |
| 4 | 3T 3.5T | ES9B-BCS-123B-J | 2500/500 | 4 | 550- 1880 | 1038 | 170 | 395 | III |
| 5 | 3T 3.5T | ES9B-BCS-132B-J | 2500/500 | 4 | 450- 1560 | 1038 | 170 | 390 | III |
| 6 | 3T 3.5T | ES9B-BCS-302B-J | 2500/500 | 4 | 460- 2060 | 1408 | 170 | 385 | III |
| 7 | 3T 3.5T | ES9B-BCS-303B-J | 2500/500 | 4 | 460- 2060 | 1408 | 170 | 385 | III |
| 8 | 3T 3.5T | ES9B-BCS-502B-J | 2500/500 | 4 | 500- 2300 | 1570 | 170 | 385 | II |
