Product description
XYD series crawler drilling machine or track mounted drilling rig is mainly used for geological general investigation and exploration,kinds of hole in concrete structure,road and tall building foundation exploration,river levees,subgrade grouting hole drilling and direct grouting,civil wells and earth temperature central air conditioner,etc.
Feature of Crawler Core Drilling Rig
1.Hydraulic control drill mast,save time and worker labor.
2.Four hydraulic jacks with max. height 1.3m,the machine can be loaded on to and unloaded from truck.
3.Rubber track is with lighter weight,and does not hurt urban road.
4.Electric-start diesel engine reduces the operator's labor intensity.
5.Mud pump:BW160 mud pump,with bigger flow displacement and pressure,easy maintenance.
6.Optional installation of hydraulic twist tube machine(75-168mm),improve work efficiency and reduce labor costs.
Parameters of Crawler Core Drilling Rig
The whole machine parameters | |||
Model | XYD-130 | XYD-180 | XYD-200 |
Drill hole depth | 130m | 180m | 200m |
Maximum opening diameter | Φ75-Φ220mm | Φ75-Φ220mm | Φ75-Φ325mm |
Final hole diameter | Φ75mm | Φ75mm | Φ75mm |
Drill pipe diameter | Φ42-60mm | Φ42-60mm | Φ42-60mm |
Borehole inclination | 90°- 75° | 90°- 75° | 90°- 75° |
Power(diesel engine) | 13.2/2200kw/r/min | 13.2/2200kw/r/min | 15/2200kw/r/min |
Size | 3.8*1.95*2.7m | 3.8*1.95*2.7m | 3.8*1.95*2.7m |
Weight without power(kg) | 3350 | 3400 | 3600 |
Vertical shaft | |||
Vertical spindle speed | 142,285,570r/min | 130,480,730,1045r/min | 64,28,287,557r/min |
Vertical stroke | 450mm | 450mm | 450mm |
Crawler chassis | |||
Crawler size/piece | 350*90*48mm | 350*90*48mm | 350*90*48mm |
Climbing angle | 20° | 20° | 20° |
Moving speed | 10km/h | 10km/h | 10km/h |
Hydraulic landing leg valid height | 1300mm | 1300mm | 1300mm |
Rig | |||
Rated load | 18t | 18t | 18t |
Effective height | 6.5m | 6.5m | 6.5m |
Mud pump | |||
Model | BW160 | BW160 | BW160 |
Flow | 160L/min | 160L/min | 160L/min |
Maximum pressure | 1.3Mpa | 1.3Mpa | 1.3Mpa |
Reciprocating frequency | 165times/min | 165times/min | 165times/min |
Inlet hose diameter | Φ51mm | Φ51mm | Φ51mm |
Outlet hose diameter | Φ32mm | Φ32mm | Φ32mm |
Machine configuration
We can provide you the full sets include the drill rig , drill pipes ,drill bits and other accessories
