Model NO.
CDZ-VT
Voltage
380V
Product Name
DC Fast EV Charging Station
Usage
Electric Appliance
Cable Length
4m/Customized
Certificate
CE FCC RoHS
Transport Package
Standard Wooden Box
Specification
680*1020*360mm
Trademark
Bluesky
Origin
Wenzhou, China
HS Code
8537109090
Production Capacity
350 Piece/Pieces Per Month
Type:
Fast EV Charging Station
Certification:
ISO, TUV, CE
Warranty:
12 Months
Combination:
Quick Charging
Connector:
CCS1/CCS2/Chademo
Color:
Customized Color
--Input & Output-- | |||
Input/Output Voltage | 380Vac±10% | Output current | 200A 3Phase |
Input frequency | 55±10% | Charging gun type | Type2 IEC 62196-2 /Type1 SAE J1772 /GB/T20234.2 |
Rated power | 60 KW | Cable length | 4m/customized |
--Protection-- | |||
Overvoltage protection | yes | Undervoltage protection | yes |
Overload protection | yes | Short circuit protection | yes |
Earth leakage protection | yes | Over temperature protection | yes |
Lightning protection | yes | Overcurrent protection | yes |
--Function and Accessory-- | |||
Network connection | No | Visual Indication | LED Indicator light |
Communication Protocol | OCPP 1.6 | Push Button | Emergency Stop |
Display | 7 inch LCD touch screen | Language | English |
RCD | Type A | RFID | yes |
--Working environment-- | |||
Protection degree | IP55 | Maximum altitude | Up to 2000m |
Environment temperature | -20ºC~+75ºC | Cooling | Natural air cooling |
Storage temperature | -40ºC~+70ºC | Operating humidity | ≤95% non-comdensing |
Applicable Scene | Indoor/Outdoor | Acoustic noise | <55dB |
Standby power consumpiton | 5W | ||
--Package-- | |||
Dimension (W/H/D) | 680*1020*360mm | Weight | 57kg |
Certificate | CE, TUV, ISO,IP55, IK10 | ||
