400kg Light Duty Platform Stacker with 1500mm Lifting Height and Stainless Steel Mast Pss4150A

Platform Stacker (HL-PS SERIES)

Simple and Easy Operation.
Lifting movement via the collapsible foot pedal.
Sensitive lowering through sinking valve.
Hard push drive.
Overload protection via a pressure valve. Bitmap

Ladder as an option.
Noise-free castor as option
Safe Operation and secure Working Conditions.
Long Service Lift.
Robust construction/Hard chromium plated frame/
Effortless Movement.
Conforms to EN1757

Model			HL-PS2085	HL-PS2120	HL-PS4085	HL-PS4120	HL-PS4150
Capacity		KG	200		400
Platform Height Max.		MM	850	1200	850	1200	1500
Platform Height Min.		MM	200
Platform Length		MM	600		650
Paltform Width		MM	500		550
Total Length		MM	940		1040
Total Width		MM	560		590
Total Height		MM	960	1310	970	1310	1610
Steering Rollers-diameter		MM	Ø125		Ø150
Frame Rollers-diameter		MM	Ø125		Ø150
Pump Strokes to Max. Height			14	21	30	45	58
Net Weight		KG	53	58	72	78	83
