Product Description
Giant Electric Off-road Pallet Stacker (CDD15-16)
This off-road stacker can meet various needs in material handling for construction sites, warehouses, animal husbandry and heavy industry workshops. It has large loading capacity and easy to operation, safe and reliable quality. With high-strength gantry, high-quality oil cylinder, the product has long service life, low maintenance cost. It is safe, reliable and durable.
Product Feature:
- Off-road rubber tires have better grip and strong load-bearing capacity. Increased vehicle height provides better pass ability, making it easy to travel on rough roads.
- Thickened load-bearing chain, multiple composite design, strong pulling force, large load-bearing, long life and safer handling.
- Stable and thickened manganese steel off-road frame designed to cope with harsh working conditions. Reliable quality with strict production process.
- High-strength hydraulic cylinder, integrated molding process, high-strength seal, stable and safe.
| MODEL | CDD15-16 |
| Capacity(KG) | 1500 |
| Max. Lifting Height(mm) | 1600 |
| Load Center(mm) | 550 |
| Fork Size(mm) | 1070*100 |
| Fork Adjustment Range(mm) | 240-680 |
| Fork leg inner width(mm) | 1280 |
| Fork leg outer width(mm) | 1590 |
| Ground Clearance(mm) | 120 |
| Length(mm) | 1960 |
| Width(mm) | 1590/850 |
| Turmning Radius(mm) | 1560 |
| Max. Drive Speed (Km/h) | 3.0/4.0 |
| Weight(kg) | 785 |
| Battery(V/Ah) | 24/100 |
| Lifting Motor(KW) | 2.2 |
| Drive Motor(KW) | 1.5 |
