MJW1.5, MJW3, MJW5, MJW10
YES
1 YAR
Mechanical Jack
Rack-Pinion Jack
1-10T
Lever
MJW1.5, MJW3, MJW5, MJW10
1.5ton~10ton
5000PCS/Month
8425421000
NU-LIFT
1PC/Carton
CE
Jiangsu, China(Mainland)
8425421000
Product Description
Product Description
•In accordance with DIN 7355
•Capacity:1.5ton~10ton.
•Our steel jacks are developed in accordance with the lastest safety regulations.With milled rack,geared wheels and tempered parts of driving gear.
•Suitable for lifting loads of any type.
•Safety crank with folding handle.
| Model | MJW1.5 | MJW3 | MJW5 | MJW10 | |
| Rated Capacity | t | 1.5 | 3 | 5 | 10 |
| Overall Dimension | mm | 151×156×1090 | 164×212×975 | 188×219×1170 | 220×274×1240 |
| Crank Force | kg | ≤28 | ≤28 | ≤28 | ≤40 |
| Rack Length | mm | 1090 | 975 | 1170 | 1240 |
| Lift H | mm | ≥800 | ≥565 | ≥700 | ≥700 |
| Net Weight | kg | 10.5 | 18.5 | 28.7 | 40 |
| Packing Dimensions | cm | 17×17.5×112.5 | 18.5×23×101 | 20.5×23.5×120.5 | 24×29.5×127.5 |
| A | mm | 100 | 120 | 120 | 140 |
| B | mm | 21 | 21 | 21 | 30 |
| C | mm | 20 | 25 | 25 | 30 |
| D | mm | 20 | 25 | 45 | 30 |
| E | mm | 12.5 | 14.5 | 17 | 21 |
| F | mm | 310 | 395 | 410 | 480 |
| G | mm | 260 | 305 | 320 | 410 |
| I | mm | 151 | 212 | 219 | 274 |
| J | mm | 156 | 164 | 188 | 220 |
| K | mm | 250 | 250 | 250 | 300 |
