Product Description
LP3 series
LP3 series is a special pump for hydraulic wrench. It is assembled in an integrated manner.
It combine independent and complete hydraulic device composed of a power unit, an electrical unit, a control device, etc.
The working pressure is high, and the oil pressure of the high-pressure outlet can be adjusted arbitrarily between 70 and 700 bar.
*Compact automatic three stage design.
*Applicable on one or two wrenches simultaneously.
*Aluminum oil tank with gauge.
*Have Φ100 high pressure gauge.
*Infinitely variable pressure adjustment between 70~700 bar.
*With the high efficiency radiator the pump can work 24 hours continuously..
*Can change the motor to fit the different voltage.
*Optional components(FP4), can operate four wrenches at the same time.
atalog No. | 675050 | 675052 |
Model | LP3-N2 | LP3-N4 |
Air Pressure(Input) | 4~8 bar | 4~8 bar |
Operating Wrench | 2 | 4 |
Tank Capacity | 5.5L | 5.5L |
Output Pressure | 8.6-2.2-1.1L/min | 8.6-2.2-1.1L/min |
Voltage | 220V/50HZ | 220V/50HZ |
Power | 3KW | 3KW |
Oil outputs | 4×1/4"NPT | 8×1/4"NPT |
Weight | 22kg | 24kg |
Volume | 44.2*28.2*37.7cm | 44.2*28.2*37.7cm |
