LMO D330
Lithium-Ion Batteries
UPS, Electric Power, Lighting
3.2V
High Discharge Rate
Square Battery
Li-ion
Fixed
Chargeable
>2.0g/cm3
0.4~0.6m2/G
>95
Gelon
Vacuum
LMO
China
Product Description
LiMn2O4 LMO Powder of Cathode Material for Lithium Ion Battery
1. Large granular
2. Low specific surface area
3. High purity
4. Good magnification rate performance
5. Excellent processing performance, Batch using compaction density in 2.9-3.1g/cc
6. High temperature cycle performance
7.1C discharge capacity more than 105mAh/g
8. Applied to high temperature and high safety performance requirements of the miner's lamp, street lamp, electric bicycles, power lithium ion battery.
TKS FOR YOUR TIME,WELCOME TO INQUIRY.
1. Large granular
2. Low specific surface area
3. High purity
4. Good magnification rate performance
5. Excellent processing performance, Batch using compaction density in 2.9-3.1g/cc
6. High temperature cycle performance
7.1C discharge capacity more than 105mAh/g
8. Applied to high temperature and high safety performance requirements of the miner's lamp, street lamp, electric bicycles, power lithium ion battery.
| -D330 | |||
| Used for | e-bicycle , electric power tool | ||
| test item | Standard | Inspection data | |
| Granularity | D10 ( μm ) | > 4.0 | 4.5 |
| D50 ( μm ) | 9.0 ~13.0 | 10.0 | |
| D90 ( μm ) | < 25 | 20.5 | |
| Tap Density ( g/cm 3 ) | > 2.0 | 2.10 | |
| Specific Surface Area (m 2 /g ) | 0.40 ~ 0.60 | 0.50 | |
| Li (%) | 3.5 ~ 4.5 | 3.55 | |
| Mn (%) | 57.0 ~ 59.0 | 57.70 | |
| Fe (%) | < 0.02 | 0.018 | |
| Cu (%) | < 0.02 | 0.018 | |
| Zn (%) | < 0.02 | 0.018 | |
| Ca (%) | < 0.03 | 0.020 | |
| Ni (%) | < 0.03 | 0.020 | |
| pH | 7.0 ~10.0 | 8.20 | |
| Moisture (%) | < 0.10 | 0.02 | |
| Circulate 100times volume retention rate (%) | > 90 | ||
| 55 degree circulate 55100times volume retention rate (%) | > 80 | ||
| capacity ( mAh/g ; button cells 1C discharge ) | > 95 | 98 | |
| Appearance | Black Powder , No Agglomeration , No Sundries | ||
| Packing | Polyethylene bag by vacuum, 25 kg/box | ||
| Storage , Delivery | Avoid moist, antiseptic | ||
| application | Lithium ion Power Battery cathode materials | ||
| use time | Six month | ||
We could supply one stop solution ( turn key project) for lithium ion battery production line.
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.
2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.
