FB30-AZ1
Overseas Service Center Available
1year
Adjustable
Electric Forklift
AC Motor
1T - 5T
Electric
500mm
3000~5000mm
New
3000kg
XCMG
Comply with Export Packaging Requirements
2475mm*1225mm*2125mm
Xuzhou, Jiangsu, China
Product Description
XCMG Official 3 Ton Small Electric Forklift Spare Parts FB30-AZ1 China 4 Wheel Drive Forklift Trucks Forklift Cheap.
1. One-piece designed of suspension frame.
2. New water tank & cooling system.
3. Larger operation space. Optimized steering wheel, operating handle, and pedals.
4. High-efficiency hydraulic system, lower fuel consumption.
5. Enhanced wide view mast improves work efficiency and operating safety.
* Full AC System
* OPS System
* Comfortable Operator Space
* Side-way Battery Change System
* Lower Energy Consumption and Energy Regeneration Function
* Easy-to-read operator display
* Front Dual AC Motor Traction System
* World Class Gear Box System
* Automatic Maintenance Alarm
* Zero-Emission, Zero-Pollution, Low-Level Vibration, Low-Level Vibration, Low Operation Cost, High Efficiency, High Quality, these are the reasons for you to choose an XCMG Electric Forklift.
* The most advanced 3-phase full AC technology in XCMG's electric range combining the Italian ZAPI electric controller, ZAPI-SUPEREC AC motors, and HAKWER battery, as well as the excellent hydraulic system, these features guarantee your material handling become the most cost-efficient.
* The Energy Regeneration Function extend extra 15% working hours, which provide the possibility for your tough and long-time working condition.
| Model | FB30-AZ1 | |
| Rated Load Capacity | Q(kg) | 3000 |
| Load Centre | C(mm) | 500 |
| Lift Height | H3(mm) | 3000 |
| Free Lift | H2(mm) | 100 |
| Fork Size (L×W×T) | L/W/T(mm) | 1070×125×45 |
| F/B(α°/β°) | Deg | 6°/12° |
| Length (To Fork Face) | L1(mm) | 2475 |
| Width | B1(mm) | 1225 |
| Mast Lowered Height | H1(mm) | 2070 |
| Mast Extended Height (With Backrest) | H4(mm) | 4070 |
| Overhead Guard Height | H5(mm) | 2125 |
| Turning Radius | Wa(mm) | 2215 |
| Fork Overhang (Wheel Center to Fork Face) | X(mm) | 485 |
| Front Tread | B2(mm) | 1000 |
| Rear Tread | B3(mm) | 980 |
| Ground Clearance | H6(mm) | 130 |
| Wheelbase | Y(mm) | 1600 |
| Fork Spread (Min/Max) | mm | 250/1100 |
| Working Aisle Width With Pallet (1000×1200,1200 Lengthways) | mm | 3970 |
| Working Aisle Width With Pallet (800×1200,800 Lengthways) | mm | 4100 |
| Travel Speed (Full Load) | km/h | 12 |
| Travel Speed (No Load) | km/h | 13 |
| Lifting Speed (Full Load) | mm/s | 280 |
| Lifting Speed (No Load) | mm/s | 440 |
| Max.Gradeability (Full Load) | % | 16 |
| Max.Gradeability (No Load) | % | 18 |
| Total Weight (Include Battery Box) | kg | 5160 |
| Tyre (Front x 2) | 28×9-15-12PR | |
| Tyre (Rear x 2) | 18×7-8-14PR | |
| Diver Motor | kw | 12 |
| Pump Motor | kw | 12 |
| Battery (Standard) | V/Ah | 80/500 |
