LHY9900D
Semi-Trailer
43m³
ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949
7000-8000mm
1840mm
Medium Duty
Mechanical Suspension
V-Shape
3 Axle
12
Not Self-dumping
ABS Anti-lock Braking System
Steel
New
HYDC
by Bulk Ship / Container Ship
8950*2550*4000mm
China, Liangshan
87163990
Product Description
| Product description | ||||||
| External dimension | 8950mm×2550mm×4000mm | |||||
| Tank body | Q235/3mm steel sheet shape: V-type | |||||
| End plate | Q345/4mm ball shape | |||||
| Axle | Number | 3 | Brand | Fuwa | Capacity | 13T |
| Suspension | Mechanical suspensions | |||||
| Leaf spring | 100mm×14mm×10 | |||||
| Tire | 12R22.5 | |||||
| Wheel rim | 8.25-22.5,9.0-22.5 steel wheel rim optional upon choice | |||||
| King pin | 2'/3.5' bolt-in type | |||||
| Landing gear | JOST, two-speed ,manual operating, heavy duty landing gear | |||||
| Manhole cover | 500mm manhole cover .2 sets | |||||
| Discharge valve | 4"disc valve | |||||
| Discharge pipe | 4"seamless aluminum alloy tube | |||||
| Braking system | Wabco re6 relay valve; t30/30 spring brake chamber ;40l air tanks | |||||
| Electrical system | Voltage 24v, receptacle 7 ways (7 wire hamess); led light, one set 6-core standard cable. | |||||
| Air-charging system | 2"main hole, 2"check valve, 1.5"safe valve, 0.4Mpa gauge | |||||
| Quadratic blow | 1"diameter check valve | |||||
| Outlet discharge pipe | 4"rubber hose. 6m. | |||||
| Accessories | One standard tool box | |||||
We are the top professional semi-trailer supplier,
We can provide you with better products and more favorable prices.
Product description and specification
30T carbon steel Bulk Cement Semi Trailer for cement, fly ash, talcum powder, flour etc.
We are semi trailer manufacturer
The trailer my company has more than 20 years production experience, has the advanced modern equipment and technology. Has a professional foreign trade team At your service.Our company's tenet is "quality is life".
Please be sure to check the accessories, looking forward to cooperating with you.
We hope to provide you with better products and more favorable prices.
Founded in 2000,huayu vehicle is specialized in manufacturing flatbed container semi trailer, low bed semi trailer, oil/fuel tank trailer, cement bulk trailer, LPG & LNG tank trailer and exporting concrete mixer truck, dump truck, tractor truck.
Partial close-up
Factory production process
Trailer advantages description
. The main components of the trailer are processed by advanced equipment, and the Main beam is welded by automatic submerged arc welding machine. All components are sandblasted to improve the paint adhesion.
. The chassis is welded with the best structure to improve the ability of handling goods and increase the effective load
· More than 20 years professional design and production experience.
· Choose Regular manufacturers purchase material.
· Use Domestic first-class production equipment. Main beam is using Submerged arc welding process.
· Famouse brand trailer parts used,like bpw/fuwa axle,triangle/double star/double coin and so on tires.
· Strict quality control system ensure that each semi trailer is qualified.
We can provide all the models you need and support customization. If you have any questions, please leave your inquiry.
INTERNATIONAL MARKET
1 .China market before the year of 2005.we can produce about 12000 pcs one year
2. In the year of 2008 we do the national business .untill now we can export 4000pcs semi-trailer one year
3. South Africa exhibation in the year 2010
4. Russia truck and trailer parts exhibation in the year 2012
5. Germany auto trailer parts exhibation in the year of 2015
6. America trailer parts exhibation in the year 2014
Diversified products
We can provide all the models you need and support customization. If you have any questions, please leave your inquiry.
