CHHGC3256Z
12 Month
Semi-Trailer
50T
ISO9001, CCC, ISO/TS16949
7000-8000mm
1820mm
Heavy Duty
Multi-link Type
Flatbed
3
12
Not Self-dumping
ABS Anti-lock Braking System
Steel
New
Fuwa or BPW Axle
Leaf Spring Suspension
Optional for Jost 2" or 3.5"
Jost Dual-Speed Landing Gear
50ton
Radial Tire 8.25r20
as Customers Request
4mm Checked Plate
550/25/30/14
CHHGC
Nude Packing
ISO, TS16949, CCC
China
87163990
Product Description
China Manufacturer Extendable Heavy-Duty Low Bed Lowboy Truck Semi Trailer (50-80 ton)
Product DescriptionSeries No | Name | Unit | Q'ty | Notice |
| 1 | Frame Dimensions | 15250*3000*1780 (1250 the height of the loading area/ Platform ) (wheelbase = 1360) Length of platform is 10.5mm Loading capacity 70Tons | ||
| 2 | Axle | piece | 3 | 14 tons BPW (Wheel track width 2360) strengthened model( wheelbase 1360 ) |
| 3 | Tire | Piece | 12 | Fengshen 10.00R-20-18 |
| 4 | Rim | Piece | 12 | Domestic Zhengxing 7.5-20 |
| 5 | Leaf-spring | piece | 6 | Domestic 10 pieces of leaf springs, which are underslung. 16thickness 100width |
| 6 | Suspension | Set | 3 | CHHGC REINFORCED TYPE |
| 7 | Relay Valve | whole vehicle | WABCO relay valve | |
| 8 | Landing gear | pair | 1 | JOST A400 (linkage) |
| 9 | Kingpin 2 | PCS | 1 | Adjustable (JOST) KZ1012 |
| 9 | Kingpin 3.5 | PCS | 1 | Adjustable (JOST) KZ1412 will be taken away, without the fifth wheel. |
| 11 | Tie-in | PCS | 4 | WABCO |
| 12 | Braking air chamber | 2 | Double chambers | |
| 13 | Floor | 6 mm checkered | ||
| 14 | Rotary support | Every side can be increased 250mm, so if the rotary supports were open the width will become 3500mm | ||
| 15 | Ramp | Pair | 1 | Width 800mm, double springs pattern, which is strengthened. As for the length, it depends on its technical specifications. |
| 16 | Top Flange thickness and Bottom Flange thickness | 20mm, 30MM width =250mm | ||
| Through beam /cross members | 12# channel steel | |||
| Side beam | 294MMH Pattern STEEL | |||
| longitudinal beam height | 600mm and the web plate thickness is 14mm | |||
| 17 | Front overhang / kingpin distance | 500MM | ||
| 18 | Spare tire holder | Will be welded on the gooseneck, and will be hand waving type. | ||
| 19 | color | Orange red | ||
| 20 | Paint | Antiseawater, whole trailer will be waxed in order to get protection from Seawater. | ||
| 21 | Marks | With CHHGC marque. | ||
| 26 | Packaging | Two units should be put as One unit | ||
| 27 | NOTICE:We send you one WABCO control valve, one single air chamber, one double air chamber as the service spare parts for free in the LOW BED SEMITRILER | |||
| 28 Notice(1) | No.2. The bearing height and front overhang/ suspension of the low-bed Semitrailer will be designed according to the 6X4 Delong Big Truck. | |||
| -2 | This configuration excludes ABS | |||
Certificate
Workshop
Business Partners
FAQ:
Q1. How to ship the vehicles?
A: By container, bulk ship, RORO.
Q2. Do you have RHD(right hand driving) vehicles?
A: Yes, noramlly we supply all LHD vehicles, and we have some RHD model vehicles.
Q3. What is your payment term?
A: We usually accept T/T or L/C depends on the quantity.
T/T, deposit in advance, and balance paid before delivery from factory.
Q4. Which model vehicles do you supply?
A: We supply all kinds of vehicles such as SUV, MPV, Pickup,van,truck, bus etc,.
Q5. What is your terms of delivery?
A: FOB, CIF.
Q6. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: What can you guarantee to your business partner?
A: Best price with good quality. We guarantee quality and after sale service to satisfy our business partners.
