TG-4A
Third Party Support
Multifunctional Pastoral Manage Machine
Agriculture
Dry Cultivating Machinery
Gasoline
Arable Machinery, Movable Operation
Traction
Gear Drive
Horizontal Axis
Orange
470-1100mm
100-200mm
150kg
4.00-7
5.5kw/7.5HP
MINGSIN
Carton Case
ISO9000
China
84322900
Product Description
TG-4A cultivator is designed with compact structure and light weight. It is suitable for the field of orchard, greenhouse, garden and other small fields. It features the following advantages:
1. Complicated gearbox design.
2. EY28 gasoline engine as the power of this model cultivator.
3. It has the differential, it is easy to steer the machine.
4. Multi-function
5. Adjustable handle bar.
| Model | Unit | TG-4A | |
| Overall dimensions | Length | mm | 1490~1700 |
| Width | mm | 680~820 | |
| Height | mm | 820~1140 | |
| Clutch type | Belt pulley tension | ||
| Steering clutch type | Automatic change, differential | ||
| Net weight | kg | 150 | |
| Tilling width | mm | 470-1100 | |
| Tilling depth | mm | 100-200 | |
| Speed | Forward 4 speeds, reverse 4 speeds | ||
| Main drive | V-belt | ||
| Tyre | 4.00-7 | ||
| Tyre inflation pressure | kPa | 100-120 (in the field) 160-180 (for transportation) | |
| PTO speed | r. p. m | Low speed706, High speed 1350 | |
| Speed of rotovator | Clockwise 8 speeds, anticlockwise 4 speeds | ||
| Driving typeof rotovator | Centre drive | ||
| Max. rotary radiusof rotovator | mm | 220 | |
| Engine | Model | EY28 | |
| Max. output | kW | 5.5 | |
| Displacement | cc | 273 | |
| Engine type | Air Cooled 4 Cycle Single Cylinder Side Valve HorizontalShaft Gasoline | ||
