High Efficiency:
Feeding capacity of 4.2 kg/s allows for efficient harvesting of crops.
Operating productivity ranges from 0.35 to 0.5 hectares per hour, making it suitable for large-scale harvesting operations.
Powerful Engine:
Equipped with a 73 kW engine, providing stable and reliable power for harvesting tasks.
Wide Working Width:
The cutting table width of 2200 mm ensures efficient harvesting across a broad area.
Flexible Operation:
Theoretical operating speed ranges from 0 to 5 km/h and 0 to 6.2 km/h, allowing for flexible adjustment based on field conditions.
Fuel Efficiency:
Unit area fuel consumption is ≤32 kg/hectare, indicating good fuel efficiency and cost savings.
Durable Design:
The overall structure is designed for durability and reliability, with a minimum ground clearance of 245 mm for easy navigation in uneven fields.
Advanced Technology:
Features such as the three-gear gearbox with hydraulic stepless transmission (HST), eccentric rake wheel design, and centrifugal fan ensure smooth and efficient harvesting operations.
User-Friendly:
The machine's compact size and ergonomic design make it easy to operate and maintain.
| Model | 4LZ-4.2S |
| Structural form | Crawler self-propelled full feeding |
| engine | 73kw |
| Dimensions | 4675 × 2300 × 2660mm |
| quality | 2870kg |
| Cutting width | 2200mm |
| Feed amount | 4.2kg/s |
| Small ground clearance | 245mm |
| Theoretical speed of operation | 0~5; 0~6.2km/h |
| Job productivity | 0.35~0.5hm2/h |
| Fuel consumption | ≤32km/hm |
| Header auger form | Telescopic transverse conveying |
| Wheel type | Eccentric type |
| Concave screen type | Grid type |
| gauge | 1150mm |
| Track Specifications | 90mm × 49 knots × 400mm |
| Gearbox type | Three-speed gearbox + hydraulic continuously variable transmission (HST) |
| Stalk chopper form | Blade rotation (optional) |
| Receiving food | Manual unloading |
Q1: Are you a factory or trading company? We have our factory for the farm machines and we also have our own trading company with self-supported import and export right.
Q2: How can I trust on your company? We are a fully registered manufacture and exporting company by China Export Registration Authorities. Moreover, our products have been exporting to a number of countries including Switzerland, Russia, Spain, Netherlands, Australia, Peru, Thailand, Pakistan, Indonesia, Tanzania, Nigeria, South Africa, Sudan, Congo etc.
Q3: Where is your factory located? How can I visit there? Our factory is located in Linyi City, Shandong Province, China. About 1 hour away from Linyi Airport, 4 hours away from Qingdao airport. All our clients are warmly welcomed to visit us!
Q4: How can I place an order from your website? It is very easy.Once you find the implement you need on our website and place an inquiry against it, or, get to the inquiry section and leave us a message there with name, country and phone number, we will get in touch with you at the earliest.
Q5: How can I make the payment? Payment is made via Telegraphic Transfer (T/T) through the bank against the proforma invoice. 30% as prepayment and the balance when the goods are ready for shipping.
Q6: What's the Payment terms? T/T, L/C or some other ways payment method.
Q7: At which port do you usually ship the good? We usually ship goods via Qingdao port of China.
Q8: How about the Warranty ? 12 months warranty from the time of the goods arrive at destination.
QC Flow:
1. Material inspection before production to avoid any potential problem from the very beginning.
2. Inspection for half-finished products during order production to find the problem earlier if any;
3. Inspection for finished products after production to make sure the products comply with customer's requirement.
Department Introduction of QC / Technical Support:
In order to get super quality, we have special QC department to control the product quality. This department is composed by experienced engineers who can offer us strong technical support easily. The engineers will inspect product quality both in order production and after order production to make sure each shipment we send to our customers is in the best status. With their strict quality control, our consistent quality wins us more and more orders from our international customers.
Full Service and Product Warranty:
We offer our customers technical assistance and a full one year warranty on all products covering all manufacturing defects. Our manufacturing facility is completely computerized to provide our customers efficiency, reliability, high quality and timely shipments.
Spare Parts:
We can supply spare parts within 15 business days or sooner. Currently, part numbers are not available on-line. You may however determine the part number from your Parts Book or, if it is a simple part, you may describe the part and send us an order online. If you are not sure, please Contact Us .
Shipment:
We can ship from our port in Qingdao or Shanghai, China to anywhere in the world within short days
We have 8-24 hours online staff to answer your technology questions and know your requirements. our staff can provide you the professional designs and recommend you the most suitable machine types.
SALES SERVICE
Provide users with comprehensive technical support,with the user selection,to provide the most economical and reasonable program. In accordance with the contract delivery time for your timely delivery,if have special requirement,our company can organize pro duction,and strive to meet user needs.
AFTER-SALES SERVICE
We have 24 hours online staff to answer your technology questions and know your requirement. Our staff can provide you the professional design andrecommend you the most suitable machine type.
SALES GOAL
We hope our outstanding quality goods and good service could make you to set up the best competitive advantages in your market.
