Skeleton Semi-trailer 2 Axle 3 Axle 4 Axle Skeleton Container Low Skeleton Semi Truck Trailer For Sale
Name | 2 axles 20ft skeleton semi trailer | 2 axles 40ft skeleton semi trailer | 3 axles 40ft skeleton semi trailer | 3 axles gooseneck 45ft skeleton semi trailer | Interlink skeleton semi trailer |
Size | 7000*2500*1500 (mm) | 12500*2500*1500 (mm) | 14000*2500*1500 (mm) | 14000*2500*1500 (mm) | 14250*2500*1500 (mm) |
Payload | 30000KG | 40000KG | 50000KG | 50000KG | 30000KG+30000KG |
Main beam | Heavy duty I beam. | Heavy duty I beam | Heavy duty I beam. | Heavy duty I beam. | Heavy duty I beam. |
Axles | 2 * 13ton capacity (Brand optional) | 2 * 13ton capacity (Brand optional) | 3 * 13ton capacity (Brand optional) | 3 * 13ton capacity (Brand optional) | 13ton capacity (2+2 or 3+3 optional) |
Twist locks | 4 pcs | 12 pcs | 12 pcs | 12 pcs | 8pcs |
Landing gear | 28 Ton two speed | 28 Ton two speed | 28 Ton two speed | 28 Ton two speed | 28 Ton two speed *2 |
Braking system | Double air chamber ,brake valve,32L air tanks ;ABS optional | Double air chamber ,brake valve,40L air tanks ;ABS optional | Double air chamber ,brake valve,40L air tanks ;ABS optional | Double air chamber ,brake valve,40L air tanks ;ABS optional | Double air chamber ,brake valve,40L air tanks ;ABS optional |
Tire | 12R22.5 8pcs (Other size optional) | 12R22.5 8pcs (Other size optional) | 12R22.5 12pcs (Other size optional) | 12R22.5 12pcs (Other size optional) | 12R22.5 24pcs (16pcs) (Other size optional) |
Rim | 9.00-22.5 8pcs (Other size optional) | 9.00-22.5 8pcs (Other size optional) | 9.00-22.5 12pcs (Other size optional) | 9.00-22.5 12pcs (Other size optional) | 9.00-22.5 24pcs (16pcs) (Other size optional) |
Suspension | Mechanical suspension (Air suspension optional) | ||||
Leaf spring | 10pcs | ||||
Kin pin | 2''/3.5'' bolt type | ||||
Electrical | LED light , 7 ways ,24V | ||||
Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting | ||||
HeNan LiShiXin transportation equipment co., LTD. is specialized in the production and export of semi-trailers(low bed semi trailer,stake semi trailer,side wall semi trailer), oil fuel tanker,and so on.We have been in this industry for many years and have a strong technical team.High quality is always our advantage.Our products are exported to all over the world and have been well received by our customers.Perfect transport system can greatly reduce the cost of customer transport.To make customers satisfied with our products and services is our constant pursuit.
1. Does your company have its own factory?
Yes, we have a factory ourselves and we have been engaged in this business in China for several years. Our factory is very famous for producing various trailers in Henan, China
2. How do we guarantee the quality?
It is always a pre-production sample before mass production;
Always perform a final inspection before shipment;
3. What can you buy from us?
Flatbed container trailers, cargo trailers, dump trucks, tank trailers, spare parts
4. What services can we provide?
Accepted delivery terms: FOB, CIF, EXW;
Accepted payment currencies: U.S. dollar, Euro, Japanese yen, Canadian dollar, Australian dollar, Hong Kong dollar, British pound, Chinese yuan, Swiss franc;
Language: English, Chinese
5. Can you meet my special requirements?
really! We are a direct manufacturer, we have strong production capacity and research and development capabilities!
