CPD35L1
Adjustable
Electric Forklift
AC Motor
3.5t
Electric
500mm
3000mm-6000mm
New
3500kg
5360kg
2 Stage / 3 Stage
1070mm
125mm
540ah/80V
Ce/ISO9001
1698mm
130mm
2400mm
EP
Standard Export Package
3660*1356*2210mm
Zhengjiang, China
8427209000
Product Description
| Distinguishing mark | |||||||
| 1.1 | Manufacturer | EP | EP | EP | EP | ||
| 1.2 | Model designation | CPD15L1 | CPD20L1 | CPD30L1 | CPD35L1 | ||
| 1.3 | Drive unit | Electrics | Electrics | Electrics | Electrics | ||
| 1.4 | Operator type | Seated | Seated | Seated | Seated | ||
| 1.5 | rated capacity | Q | t | 1.5 | 2 | 3 | 3.5 |
| 1.6 | Load center distance c mm | 500 | 500 | 500 | 500 | ||
| 1.8 | Load distance,centre of drive axle to fork | x | mm | 405 | 405 | 500 | 500 |
| 1.9 | Wheelbase y mm | 1470 | 1470 | 1698 | 1698 | ||
| Weight | |||||||
| 2.1 | Service weight (include battery) | kg | 2640 | 2950 | 4830 | 5360 | |
| 2.2 | Axle loading, laden driving wheels /steering wheels kg | 3615/525 | 4380/570 | 6840/990 | 7750/1110 | ||
| 2.3 | Axle loading, unladen driving wheels /steering wheels | kg | 1190/1450 | 1155/1795 | 2065/2765 | 2185/3175 | |
| Types,Chassis | |||||||
| 3.1 | Tyre type,driving wheels /steering wheels | Solid rubber | Solid rubber | Solid rubber | Solid rubber | ||
| 3.2 | Tyre size, driving wheels | 18X7-8 | 200/50-10 | 23X10-12(578X228) | 23X10-12(578X228) | ||
| 3.3 | Tyre size, steering wheels | 5.00-8 | 5.00-8 | 200 /50-10(453X194) | 200/50-10(453X194) | ||
| 3.5 | Wheels, number driving/steering (x=drive wheels) mm | 2x/ 2 | 2x/ 2 | 2x/ 2 | 2x/ 2 | ||
| 3.6 | Tread, Driving wheels | b10 | mm | 910 | 910 | 1100 | 1100 |
| 3.7 | Tread, Steering wheels b11 mm | 920 | 920 | 1020 | 1020 | ||
| Dimensions | |||||||
| 4.1 | Tilt of mast/fork carriage forward/backward | α/ β (°) | 6/ 11 | 6/ 11 | 5/ 9 | 5/ 9 | |
| 4.2 | Height, mast lowered h1 mm | 2080 | 2080 | 2210 | 2210 | ||
| 4.3 | Free lift (load backrest) | h2 | mm | 95 | 95 | 140 | 140 |
| 4.4 | Lift height h3 mm | 3000 | 3000 | 3000 | 3000 | ||
| 4.5 | Height, mast extended | h4 | mm | 4015 | 4015 | 4130 | 4130 |
| 4.7 | Height of overhead guard (cabin) h6 mm | 2080 | 2080 | 2210 | 2210 | ||
| 4.8 | Seat height | h7 | mm | 1050 | 1050 | 1120 | 1120 |
| 4.12 | Tow center of pin height h10 mm | 360 | 360 | 380 | 380 | ||
| 4.19 | Overall length | l1 | mm | 3270 | 3270 | 3640 | 3660 |
| 4.20 | Length to face of forks l2 mm | 2200 | 2200 | 2570 | 2590 | ||
| 4.21 | Overall width | b1/ b2 | mm | 1080 | 1080 | 1356 | 1356 |
| 4.22 | Fork dimensions s/ e/ l mm | 40×100×1070 | 40×100×1070 | 45×125×1070 | 50×125×1070 | ||
| 4.23 | Fork carriage class/type A, B | 2A | 2A | 3A | 3A | ||
| 4.24 | Fork carriage width b3 mm | 1040 | 1040 | 1228 | 1228 | ||
| 4.31 | Ground clearance, laden, below mast | m1 | mm | 110 | 110 | 130 | 130 |
| 4.32 | The minimum ground clearance of frame m2 mm | 105 | 105 | 125 | 125 | ||
| 4.34.1 | Aisle width for pallets 1000 × 1200 crossways | Ast | mm | 3685 | 3685 | 4090 | 4100 |
| 4.34.2 | Aisle width for pallets 800 × 1200 lengthways Ast mm | 3885 | 3885 | 4290 | 4300 | ||
| 4.35 | Turning radius | Wa | mm | 2080 | 2080 | 2390 | 2400 |
| Performance data | |||||||
| 5.1 | Travel speed, laden/ unladen km/ h | 10.5/14 | 10.5/14 | 15/16 | 15/16 | ||
| 5.2 | Lifting speed, laden/ unladen | m/ s | 0.3/ 0.42 | 0.28/ 0.42 | 0.4/0.45 | 0.4/0.45 | |
| 5.3 | Lowering speed, laden/ unladen m/ s | 0.42/ 0.45 | 0.43/ 0.45 | 0.44/ 0.48 | 0.44/ 0.48 | ||
| 5.5 | Drawbar pull, laden/unladen | N | - | - | - | -- | |
| 5.6 | Max. drawbar pull, laden/unladen (time) N | - | 10000 | - | 17800 | ||
| 5.7 | Gradeability, laden/unladen | % | - | - | - | -- | |
| 5.8 | Max. gradeability, laden/unladen % | 10.5/14 | 10.5/14 | 16/20 | 16/20 | ||
| 5.10 | Service brake type | Electromagnetic | Electromagnetic | Mechanics+ Hydraulic | Mechanics+ Hydraulic | ||
| park brake type | Electromagnetic | Electromagnetic | Mechanical | Mechanical | |||
| Electric-engine | |||||||
| 6.1 | Drive motor rating S2 60 min | kW | 6 | 6 | 16.6 | 16.6 | |
| 6.2 | Lift motor rating at S3 15% kW | 7.5 | 7.5 | 24 | 24 | ||
| 6.3 | The maximum allowed size battery | mm | - | - | 891 X 550 X 680 | 891X550X680 | |
| 6.4 | Battery voltage/nominal capacity K5 | - | - | 80V 540AH | 80V540AH | ||
| 6.5 | Battery weight | kg | - | - | 420 | 420 | |
| Standard battery pack capacity V / AH | 48V / 360AH | 48V / 360AH | 80V / 540Ah | 80V / 540Ah | |||
| Chemical Material | LFP | LFP | LFP | LFP | |||
| Charger V / A | 48V / 150A | 48V / 150A | 80V / 200A | 80V / 200A | |||
| Addition data | |||||||
| 8.1 | Type of drive unit | AC | AC | AC | AC | ||
| 10.5 | Steering type | - | - | - | - | ||
| 10.7 | Sound pressure level at the driver's ear | dB (A) | - | - | 70 | 70 | |
Company Information
Packaging & Shipping
Our Service
EP is no longer just a manufacturer of material handling equipment, but an excellent before, during and after sales service provider. EP is the factoy in China who issue online service system for customers,Including 4 ways as following:1,Online claim system;
2,Online technique system;
3,Online forklift tracking system;
4,Online spare parts order system.
EP's online service and 24 hours reply system ensure that EP customers get the most cost-efficient products.
Global Network
After years of hard work, EP has established a sales network with more than 300 distributors in around 40 countries around the world. The worldwide network provides you quick and professional service.
