4 OPZV 2V 200AH Battery
Lead-Acid Batteries
UPS, Electric Power, Boat, Solar System
2V
Low Discharge Rate
Square Battery
Acid
Fixed
Chargeable
HUJHON
Wooden Box
103*206*356*389mm
China
8507200000
Product Description
HUJHON - 4OPzV 200AH @ 10HR
Rechargeable Sealed Lead Acid Battery OPZV-Tubular Plate Series
The OPZV 200AH is part of our OPzV range of tubular plate gel batteries which have been designd to offer superior cyclic performance. the 2V 200AH @ 10hr. rate OPzV battery has a desigen life up to 20 years and has excellent deep discharge recovery making it the ideal battery for a variety of critical cyclic application including renewable energy. telecoms, power station and signals.
HUIZHONG POWER'S cutting-edge manufacturing and process control combined with meticulous quality assurance procedures guarantee consistent and dependable performance.
HUIZHONG POWER'S cutting-edge manufacturing and process control combined with meticulous quality assurance procedures guarantee consistent and dependable performance.
FEATURES
∧ Tubular plate and gel electrolyte for increased performance, service life and reliability.
∧ Superior cyclic performance.
∧ Enhanced overcharge endurance.
∧ 20 year design life in fl oat applications.
∧ Excellent recovery from over discharge situations.
∧ Rugged impact resistant ABS case and cover (UL94-HB) Also available to UL94-V0.
APPROVALS
∧ ISO9001:2015 - Quality management systems.
∧ CE
∧ IEC 60896-21 22
∧ BSCI
∧ MSDS
PERFORMANCE SPECIFICATIONS
| Nominal Voltage | 2 volts (1 cell) |
| Nominal Capacity | |
| 100-hr. (1.80 volts) | 252.8 AH |
| 20-hr. (1.80 volts) | 213.8AH |
| 10-hr. (1.80 volts) | 200.0 AH |
| 5-hr. (1.75 volts) | 175.5 AH |
| 3-hr. (1.75 volts) | 155.7 AH |
| 1-hr. (1.60 volts) | 114.0 AH |
| Approximate Weight | 39.7 lbs. (18kg) |
| Internal Resistance (approx.) | 1.1 milliohms |
| Shelf Life (% of nominal capacity at 68°F (20°C) | 1 Month 97%/ 3 Month 91%/ 6 Month 83% |
| Operating Temperature Range | Charge 5°F (-15°C) to 122°F (50°C) |
| Discharge -4°F (-20°C) to 140°F (60°C) | |
| Case | ABS Plastic |
APPROVALS
∧ Cycle Applications: Apply constant voltage charge at 2.35v/c - 2.45v/c (14.1 - 14.7v for 12v Monobloc) at 20°C. Initial charging current should be set at less than 0.25C Amps. Switch to fl oat charge to avoid overcharging.
∧ "Float" or "Stand-By" Service: Apply constant voltage charge of 2.25v/c - 2.30v/c (13.5 to 13.8 volts for 12v Monobloc at 20°C. When held at this voltage, the battery will seek its own current level and maintain itself in a fully charged condition.
∧ Temperature Compensation: Charging Voltage for both Cyclic and Standby applications should be regulated in relation to ambient temperature. As temperature rises charging voltage should be reduced to prevent overcharge and increased as temperature falls to avoid undercharge.
For further charging information including temperature compensation factors, see our Technical Manual/ Charger specifications.
APPLICATIONS
∧ Solar ∧ Wind ∧ Telecommunications
∧ UPS ∧ Utilities ∧ Signalling (airport, railway, seaport)
FURTHER INFORMATION
Please contact with us for more informations about OPzV series batteries!
