Manual Chain Hoist HSZ-A 619 Series

Manual Chain Hoist HSZ-A 619 Series

Manual chain hoists are commonly known as chain blocks and are designed
For heavy duty lifting and materials handling operations. Chain blocks raise and lower loads by pulling on the hand chain. Chain blocks can be of single or double fall configurations depending on the capacity of the block.

Product Features:

1. UNIQUE OVERLOAD STRUCTURE

A) The adoption of the overload limitation designed by ourselves. (extra choose)

B) The adoption of needle bearing and antifriction bearing.

2. Use a drawn cup needle roller bearing at a joint position between the long axis and the load chain wheel.

3. Use a antifriction bearing at a joint position between the long axis and the side fascla in order to improve the hoist's flexibility and efficiency.

4. Look release device.

5. The adoption of the bottom hook housing bearing.

6. By using the new pattern of the bottom hook assembly made by ourselves, the bottom hook can flexible operate for 360 degree.

Model		HSZ-0.5A	HSZ-1A	HSZ-1.5A	HSZ-2A	HSZ-3A	HSZ-5A	HSZ-10A	HSZ-20A	HSZ-30A	HSZ-50A
Rated Capacity	t	0.5	1	1.5	2	3	5	10	20	30	50
Standard Lifting Height	m	2.5	2.5	2.5	3	3	3	3	3	3	3
Running Test Load	kn	6.1	12.3	18.4	24.5	36.8	61.1	91.9	235.2	367.5	612.5
Effort Required to Lift Rated Load	N(kg)	200	320	360	365	385	435	414	414× 2	435× 2	435× 2
Strands of   Load Chain		1	1	1	1	2	2	4	8	12	22
Laod Chain Diameter	mm	6	6	8	8	8	10	10	10	10	10
Dimension (mm)	A	137.5	146.5	170	170	170	190	190	209	312	406
	B	137	162	183	194	220	288	384	625	691	962
	C	270	317	399	414	465	636	798	890	1380	2578
	D	35	35.5	45	42.5	50	64	85	110	110	170
	k	28	26	32.5	32	37	46	64	85	85	85
N. W.	kg	10	12	19	20	27	45.5	83	193	220	1092
Packing Measurement	cm	22× 15× 19.5	23× 18× 19.5	23× 18× 19.5	28× 21× 24	32× 21× 26	40× 21× 31	50× 41× 21	64× 38× 64	72× 50× 68	110× 100× 130
Extra Weight per Meter of Extra 1 Meter Lift	kg	1.7	1.7	2.3	2.3	3.7	5.6	9.7	19.4	29.1	53.4
