| Type | SDYG-Z 0509 | SDYG-Z 0510 | SDYG-Z 0511 | SDYG-Z 0513 | |
| Load capacity | Q(Kg) | 500 | 500 | 500 | 500 |
| Load center | C(mm) | 400 | 400 | 400 | 400 |
| Type of lifting | / | Electric | Electric | Electric | Electric |
| Operating type | / | Walkie | Walkie | Walkie | Walkie |
| Material | / | Nylon/PU | Nylon/PU | Nylon/PU | Nylon/PU |
| Wheel base | y(mm) | 860 | 860 | 860 | 860 |
| Front wheel base | b11(mm) | 380 | 380 | 380 | 380 |
| Rear wheel base | b10(mm) | 670 | 670 | 670 | 670 |
| Quantity of steering/ beering/balancewheel | 2002/2/6 | 2002/2/6 | 2002/2/6 | 2002/2/6 | |
| Bearing wheel size | mm | Φ70×60 | Φ70×60 | Φ70×60 | Φ70×60 |
| Steering wheel size | mm | Φ100×50 | Φ100×50 | Φ100×50 | Φ100×50 |
| Balance wheel size | mm | Φ40×26 | Φ40×26 | Φ40×26 | Φ40×26 |
| Train wheel size | mm | Φ30×26 | Φ30×26 | Φ30×26 | Φ30×26 |
| Min fork size | mm | 90 | 90 | 90 | 90 |
| Maximum lifting height of fork | h3(mm) | 900 | 1000 | 1100 | 1300 |
| Fork outside width | mm | 535 | 535 | 535 | 535 |
| fork inside width | mm | 225 | 225 | 225 | 225 |
| Fork length | l(mm) | 1150 | 1150 | 1150 | 1150 |
| Single fork size | e/s(mm) | 155/60 | 155/60 | 155/60 | 155/60 |
| Overall length | L1(mm) | 1600 | 1600 | 1600 | 1600 |
| Overall width | b1(mm) | 790 | 790 | 790 | 790 |
| Overall height | h1(mm) | 1200 | 1300 | 1400 | 1600 |
| Whole height | h4(mm) | 2100 | 2300 | 2500 | 2900 |
| Length of vertical surface to | l2(mm) | 1150 | 1150 | 1150 | 1150 |
| Min. turning radius | Wa(mm) | 1120 | 1120 | 1100 | 1120 |
| Max. lifting speed | mm/s | 80/110 | 80/110 | 80/110 | 80/110 |
| Max.dropping speed | mm/s | 80/80 | 80/80 | 80/80 | 80/80 |
| Lift motor | V/Kw | 12/0.8 | 12/0.8 | 12V0.8 | 12V0.8 |
| Battery capacity | V/Ah | 12/33 | 12/33 | 12/33 | 12/33 |
| Battery weight | Kg | 10 | 10 | 10 | 10 |
| Weight | Kg | 175 | 186 | 197 | 219 |
Anhui VMAX TECHNOLOGY Co., Ltd.. is located in Lu'an, Anhui,China. We are one of the biggest forklift manufacturers in China,which has 67,000 square meter area workshop and outputs 5,000 sets forklifts annually. We have different kinds of large blazing cutter, plasma cutter, large punch machine, CNC machining center, large painting machine and other high-class machines and testing equipment which ensure perfect quality of each forklift from NIKIYUMAX. Now our products include counter-balance diesel forklift,battery forklift, gas/lpg forklift, pallet truck, stacker, reach truck, mast mobile container crane, etc. With firstclass technology and stable quality, NIKIYUMAX products won the appreciation form majority of overseas customers. Our products have beenexported to Europe, America, the Middle East, Southeast Asia, Africa and many other countries and regions. More than 400 NIKIYUMAX members offer you products with top-class service. We sincerely welcome you to visit us.
1. What Certificate do you have?
VMAX workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate and SGS.
2. Can you customize and design as the clients' requirement?
VMAX will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
Warranty time:
Normally 1 year or 2000 working hours whichever occurs first.
4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, balance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.
6. Delivery time:
Standard configuration products are always in stock.
7.Production Time: Within 20 days after order confirmed
