XR220D
1 Year
CE, RoHS, ISO 9001:2000, ISO 9001:2008
Used
2000mm
67m
Multifunction
Rotary
Crawler
242kw
7-25r/Min
XCMG
Comply with Export Packaging Requirement
8968*4400*22180mm
Xuzhou, Jiangsu, China
87059091
Product Description
XCMG 2020 Year XR220D China Used Hydraulic Rotary Drilling Rig Machine
XCMG XR220D Rotary Drilling Rig widely used in boring operation of bored concrete pile in foundation engineering of highway, railways, bridges, ports, docks and high-rise buildings.The machine adapt single row rope for main winch to figure out the wear of steel rope. and extend the life-span.
With infrared camera for observing main winch, Manipulator can observe the state of steel rope at day and night in cab. With the hydraulic pressure system adopted threshold power control and positive flow control, the system acquired high efficiency and higher energy conservation.
With infrared camera for observing main winch, Manipulator can observe the state of steel rope at day and night in cab. With the hydraulic pressure system adopted threshold power control and positive flow control, the system acquired high efficiency and higher energy conservation.
The patented parallelogram articulated structure actualizes a wider work range. The highly strengthened box-type steel structure design makes the mast of highly-rigidity and anticontored, therefore the drill accuracy is heightened.
Description | Unit | Parameter | |
Max. drilling diameter | mm | 2000 | |
Max. drilling depth | m | 67 | |
Engine | Model | QSL-325 | |
Rated power/speed | kW | 242/(2200r/min) | |
Rotary drive | Max. torque | kN.m | 220 |
Rotational speed | r/min | 7-25 | |
Crowd cylinder | Max. Pushing force | kN | 200 |
Max. Pulling force | kN | 200 | |
Max. stroke | mm | 5000 | |
Main winch | Max. pulling force | kN | 230 |
Max. single-rope speed | m/min | 70 | |
Diameter of the steel wire rope | mm | 30 | |
Auxiliary winch | Max. pulling force | kN | 80 |
Max. single-rope speed | m/min | 60 | |
Diameter of the steel wire rope | mm | 20 | |
Traveling | Max. traveling speed of the overall unit | km/h | 1.5 |
Max. climbable gradient of the overall unit | % | 35 | |
Hydraulic system | Working pressure | MPa | 35 |
Rotary table slewing angle | ° | 360 | |
Weight of overall unit | t | 76 | |
Dimension | Working condition | mm | 8968*4400*22180 |
Transportation condition | mm | 16360*3250*3535 | |
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted.
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC.
3: What about the delivery time?
A: 7-30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
