HTLP0.3-12
Long Life
One Year
Telescoping Lift
320kg
Self-propelled
AC
Moving
CE
12m Electric Crawler Platform
Htlp0.3-12
320kg
113kg
2
14m
12m
2600mm
1170mm
HIGHTOP
Wooden Case
2700*1300*2100mm
Shandong
Product Description
320kg 4meter-12meter Mini Manual Scissor Lift Scissor Lift Platform Work Platform
Product Description
320kg capacity lift vertical aerial work platform Outdoor rough terrain lifting platform
Self-propelled scissor lift has its own walking and lifting function, with the steering wheel to control the direction of running, speed can walk and a brake device, battery driven DC motor running and movements, may also choose to AC motor or diesel engine running and movements, can also use wireless electronic remote control movements, without the need for manual traction and does not need an external power supply, flexible and convenient in movement, high-altitude operations more efficient and convenient is modern enterprise, safety production ideal high- altitude operations equipment.
PRODUCT SPECIFICATIONS
| Model | HTLP0.3-12 |
| Safe working load | 320 KG |
| Safe working load of extension | 113 KG |
| Max.number of people | 2 |
| Max.working height | 14 m |
| Max.platform height | 12 m |
| Overall length | 2600 mm |
| Overall width | 1170 mm |
| Overall height(fence not folded) | 2640 mm |
| Overall height(fence folding) | 1940 mm |
| Working platform size(L*W) | 2400 mm*1170 mm |
| Platform extension size | 0.7 m |
| Min.ground clearance(retracted) | 0.1 m |
| Min. Ground clearance(lifting) | 0.019 m |
| Wheelbase | 1.89 m |
| Min.turning radius(inner wheel) | 0 |
| Min.turning radius(outer wheel) | 2.2 m |
| Lifting motor/drive motor | 24 v/4.0 kw |
| Machine travel speed(stowed) | 3.5 km/h |
| Machine travel speed(lifting state) | 0.8 km/h |
| Up/down speed | 80/90 sec |
| Battery | 6 V/230 ah |
| Charger | 24 V/25 A |
| Max.Climb capacity | 25 degree |
| Max. allowable working angle(indoor/outdoor) | 2° /3° |
| Type | 381*127 |
| Weight of whole machine | 2800 kg |
