KDF30
CE, RoHS, ISO 9001:2000, ISO 9001:2008
New
AC Motor
>300mm
>300m
Cone Bit
Impactor
Metallic and Non-Metallic Ore Excavator
11× 1.65× 2.8m
10000kg
57W
280mm
KUDAT
Nude in Container
CE
China
8430390000
Product Description
KDF281 hydraulic rock drill
China hydraulic rock drill
China hydraulic rock drill
This rock drill is used to drill blast holes for big section tunneling constructions in mining, metallurgy, water and electricity, railway, highway engineering, etc. The advanced hydraulically controlled drilling system which is safe and simple to operate incorporates the auto stop and anti jamming function. It is equipped with 4 hydraulic legs to stabilize. This kind of jumbo can walk flexibly with rubber wheels and direct diesel drive. The articulated heavy carrier and the four wheels drive are suited to work in narrow tunnels and mine roadways.
| Type | KDF30(Single arm) | |
| Overall size(Length/Width/Height) (m) | 11×1.65×2.8 | |
| Body | Hole diameter (mm) | 32~102 |
| Drifter rod length (m) | 5350 | |
| Hole depth (once) (m) | 5000 | |
| Cross section | 3.5×3.5-7.5*8 | |
| (length*width) (m) | ||
| Total weight (kg) | 10000 | |
| Engine power (kw) | 57 | |
| Carrier | Articulated steering | ±45° |
| Approach and departure angle | 15° | |
| Min, ground clearance (mm) | 280 | |
| Drive mode | Four wheel drive | |
| Type | 1×ZBS*** | |
| Boom | Up/Down | 55°/42° |
| Swinging angle | 42°/42° | |
| (Inner/ Outer) | ||
| Rotation angle | 180°/180° | |
| (positive/ negative) | ||
| Boom companding (mm) | 1300 | |
| Horizontal hold | Completely | |
| Extension (mm) | 1500 | |
| Impeller | Type | TJZ4.5 |
| Up/Down | 60°/14° |
