TH1254
18 Months
18 Months
Wheel Tractor
Farm Tractor, Garden Tractor, Lawn Tractor
ISO, CE, CCC
4WD
Euro III
Gas / Diesel
6-10 Years
Large
Red
New
2660
1650/1850/1950
1700-2300
425mm
4580kg
Dry Type Double Action
Hydraulic Steering
16f+8r
Weichai Engine
2200(R/Min)
13.6-24
16.9-34
540/1000r/Min
Two Pairs
6 Cylinder Engine
Taihong Brand
Professional Package
4950mm x 2300mm x 2850mm
Shandong, China
8701941090
Product Description
China Factory Directly Supply 15HP-260HP Tractor With Farm Machine
Characteristic
(1) Compact structure, convenient operation, flexible steering, traction, versatile and easy maintenance characteristics.
(2) Dual stage clutch,16F+8R gearshift, hydraulic steering, double stage clutch and the 3-point linkage is adjustable by floating way.
(3) Adopt YTO/Weichai engine, Chinese famous diesel engine , quality assurance;
(4)Rear three-point suspension, multi way valve, equipped all kinds of the farm implement
(5)Streamlined design, novel and beautiful appearance
TD Big Chassis Series 16F+8R Gearshift Yto/Weichai Six-Cylinder Engine Tractor
1.Fully enclosed air-conditioned cab, good sealing, anti noise, wide vision and comfortable driving.
2.Different hood type and color can be choosed.
3.Rear three-point suspension, multi way valve, equipped all kinds of the farm implement
We supply all kinds of tractor implements, like front end loader, backhoe, disc plough, disc harrow, rotary tiller, cultivator, sprayer, corn soya planter/ seeder, rice transplanter, rice harvester, rice mill, potato harvestor, mower, front end loader and backhoe, snowbrush, hay baler, planter etc. We provide you good prices with high quality.
4.Company Introduction
Weifang Taihong Tractor Co.,Ltd established in 1990, with coverage of 206677 square meters, is one of the most professional tractor manufacturer in China. With 30 years development, Taihong is capable of producing tractor from 30HP to 260HP and has a large market share at home and abroad. Taihong has its own foundry, casting, machinery processing center. Some parts are made by itself to realize the whole quality control from spare parts.
5.Certification and Honors
We have passed ISO9001, CE, CCC and other international export certification
6.Service and Warranty
1. Spare Parts - For easy-damage parts, we will send you together with the tractor for free.
And in the warranty period, if the spare part does not work because of the quality, we will send you new parts for free..
2. Warranty time: 18 months after the tractor delivery to your port.
3. Delivery time: 15 days for one container.
4. Every color can be Ok.we can do for you.
5. We can do the tractor with your logo in your orders. (It Is Free)
6. Payment term: 30% T/T in advance, 70% T/T before shipping.
7.Packing and Delivery
Fast Delivery Time ,Professional Package,40HQ load 2 pcs tractor,Or use trucks
8.FAQ
1. Q: Are you a factory or a trading company?
We are a professional manufacturer of tractors. It has more than 30 years of experience.
2. Q: Can we use our logo or design?
Sure,OEM is welcome any time.we can also provide whole tractor model design.
3. Q:About price
The price is negotiable. It can be changed according to tractor optional or package.
4. Q:what's your payment terms?
Normally we use T/T, we also accept other payment terms,such as Wstern Uion,Pypal and L/C
5. Q: What's your MOQ?
1 set.
6.Q:what's the tractor optional parts?
Can be equipped with air Pump,Anti-flap,Awning,Other engine,Paddy tire,A/C cab,Double tire or your requipment.
7. Q: How is your after-sales service?
A: give us an e-mail or video. Our engineers and I are very willing to solve this problem for you. We have not only high quality machines, but also good after-sales service.
Looking forward to our cooperation
9.Contact us
Welcome to our Factory
Insisting on operation tenet of "good faith and quality first", we do our best to provide best products and whole-hearted service. We actively cooperate with research institutes and transnational corporation, in order to realize constant innovation. Weifang TaiHongTractor Co., Ltd. warmly welcomes domestic and abroad customers to visit us!!
Mrs.Lucy
Characteristic
(1) Compact structure, convenient operation, flexible steering, traction, versatile and easy maintenance characteristics.
(2) Dual stage clutch,16F+8R gearshift, hydraulic steering, double stage clutch and the 3-point linkage is adjustable by floating way.
(3) Adopt YTO/Weichai engine, Chinese famous diesel engine , quality assurance;
(4)Rear three-point suspension, multi way valve, equipped all kinds of the farm implement
(5)Streamlined design, novel and beautiful appearance
TD Big Chassis Series 16F+8R Gearshift Yto/Weichai Six-Cylinder Engine Tractor
| Main Technical Data of TH1254 Tractor | ||
| Tractor parameters | Model NO | TH1254 |
| Type | 4 x 4 wheeled drive | |
| L x W x H(mm) | 5270 x 2380 x 3160 | |
| Wheel base(mm) | 2700 | |
| Front wheel tread(mm) | 1760,1860,1960,2060 | |
| Rear wheel tread(mm) | 1700 2300 | |
| Min ground clearance | 370mm | |
| Dry mass(kg) | 4860 | |
| Clutch | 14''clutch,Dry type double action constantly connecting | |
| Steering | hydraulic steering | |
| Transmission box | 16F +8R Shifts | |
| Engine brand | Weichai engine | |
| Engine data | Engine type | Inline,cooled water,four stroke |
| Engine Rated power | 95.6kw | |
| Engine Rated speed | 2200(r/min) | |
| Fuel | diesel | |
| Tyre | Front Tyre | 13.6-24 |
| Rear Tyre | 16.9-34 | |
| PTO | Hydraulic outlet | Two pairs |
| Suspension type | Rear position,rear three point suspension category ii | |
| Pto speed | 760/850 r/min or 540/1000 r/min | |
| Pto shift & spline size | 35 spline 6 teeth | |
1.Fully enclosed air-conditioned cab, good sealing, anti noise, wide vision and comfortable driving.
2.Different hood type and color can be choosed.3.Rear three-point suspension, multi way valve, equipped all kinds of the farm implement
We supply all kinds of tractor implements, like front end loader, backhoe, disc plough, disc harrow, rotary tiller, cultivator, sprayer, corn soya planter/ seeder, rice transplanter, rice harvester, rice mill, potato harvestor, mower, front end loader and backhoe, snowbrush, hay baler, planter etc. We provide you good prices with high quality.
4.Company Introduction
Weifang Taihong Tractor Co.,Ltd established in 1990, with coverage of 206677 square meters, is one of the most professional tractor manufacturer in China. With 30 years development, Taihong is capable of producing tractor from 30HP to 260HP and has a large market share at home and abroad. Taihong has its own foundry, casting, machinery processing center. Some parts are made by itself to realize the whole quality control from spare parts.
5.Certification and Honors
We have passed ISO9001, CE, CCC and other international export certification
6.Service and Warranty
1. Spare Parts - For easy-damage parts, we will send you together with the tractor for free.
And in the warranty period, if the spare part does not work because of the quality, we will send you new parts for free..
2. Warranty time: 18 months after the tractor delivery to your port.
3. Delivery time: 15 days for one container.
4. Every color can be Ok.we can do for you.
5. We can do the tractor with your logo in your orders. (It Is Free)
6. Payment term: 30% T/T in advance, 70% T/T before shipping.
7.Packing and Delivery
Fast Delivery Time ,Professional Package,40HQ load 2 pcs tractor,Or use trucks
8.FAQ
1. Q: Are you a factory or a trading company?
We are a professional manufacturer of tractors. It has more than 30 years of experience.
2. Q: Can we use our logo or design?
Sure,OEM is welcome any time.we can also provide whole tractor model design.
3. Q:About price
The price is negotiable. It can be changed according to tractor optional or package.
4. Q:what's your payment terms?
Normally we use T/T, we also accept other payment terms,such as Wstern Uion,Pypal and L/C
5. Q: What's your MOQ?
1 set.
6.Q:what's the tractor optional parts?
Can be equipped with air Pump,Anti-flap,Awning,Other engine,Paddy tire,A/C cab,Double tire or your requipment.
7. Q: How is your after-sales service?
A: give us an e-mail or video. Our engineers and I are very willing to solve this problem for you. We have not only high quality machines, but also good after-sales service.
Looking forward to our cooperation
9.Contact us
Welcome to our Factory
Insisting on operation tenet of "good faith and quality first", we do our best to provide best products and whole-hearted service. We actively cooperate with research institutes and transnational corporation, in order to realize constant innovation. Weifang TaiHongTractor Co., Ltd. warmly welcomes domestic and abroad customers to visit us!!
Mrs.Lucy
