Introducing the revolutionary Deep Cycle 12V100ah Lifpo4 Battery for Off-Grid with BMS! Engineered with state-of-the-art technology, this LiFePO4 battery by Shenyang Lanjian Technology Co., Ltd promises exceptional performance and reliability for all your off-grid needs. Experience unparalleled power storage with integrated Battery Management System (BMS) ensuring safety, longevity, and efficient energy utilization. Whether you're powering a remote home, a mobile setup, or exploring renewable energy solutions, this battery is your ultimate companion for off-the-grid adventures.
| Model: | 12V100Ah | Max. continuous charge current | 1C/1C |
| Recommended scope of SOC | 10% - 90% | Max. continuous discharge current: | 2C/2C |
| Storage temperature | 0ºC~35ºC(1 year) | Operating temperature charge: | 0ºC to 60ºC |
| Rated capacity: | 100Ah | Operating temperature discharge: | -30ºC to 60ºC |
| Nominal voltage: | 12.8V | Cell weight: | 12.5kg |
| Operating voltage: | 10V~12.8V | Dimension(T*W*H)mm: | 330*172*215MM |
| Chemistry: | LiFePO4 (Lithium Iron Phosphate) | AC Impedance Resistance(1KHZ) | ≤0.5mΩ |
| Cycle life: | ≥8500 cycles @ 0.2C 80% DOD(temperature: 25±2ºC) | Certification | CE/UN38.3/CB, RoHS |
Grade A Cells & BMS Protection Maintenance-Free & No Leakage Our batteries liberate you from the hassle of acid leaks and constant maintenance. Equipped with sophisticated circuit safeguards like 1. Over-discharge protection, 2. Overcharge protection, 3. High-temperature protection, 4. Short-circuit protection, 5. Battery cell protection, 6. Overcurrent protection, 7. Over voltage protection, and 8. Thermal protection, these batteries promise unparalleled reliability.Extended Service
Lifetime Crafted with corrosion-resistant grids, these batteries boast a remarkable design life of up to 8 years for standby applications and deliver over 4500+ charge/discharge cycles for cyclic uses.
Longer Shelf Life Enjoy the convenience of not needing to recharge the dormant battery frequently.
Install Them Anywhere Maintenance-free, without leakage, toxic gas generation, and resistant to vibrations, these Deep Cycle Batteries excel in high and low temperatures. They are versatile, supporting various systems such as marine, RV, van, off-grid, home backup power, and more!
Note: Products equipped with electrical plugs can be customized for different countries. As outlets and voltage vary internationally, an adapter or converter might be needed for your destination. Ensure compatibility prior to purchase.
Sealed Battery, Safe Charging
Advanced valve-regulated technology ensures the battery is maintenance-free, leak-proof, and gas-free.Special treatment of plate grids delivers exceptional discharge performance.
Long Shelf Time
When not in use, the monthly self-discharge rate of this Deep Cycle sealed battery is impressively low at 3% at 77ºF (25ºC), which is fivefold lower than traditional flooded variants.
Power Most Appliances
The battery's consistent and stable discharge seamlessly powers most household appliances, including microwaves, CPAP machines, coffee makers, laptops, and more.
Better Performance at Extreme Temperatures
Ensures stable battery capacity and remarkable discharge performance from 5ºF (-15ºC) to 122ºF (50ºC).
Engineered with solar energy storage in mind, the battery delivers optimum performance even in freezing conditions.
In Series and In Parallel
You can connect up to 4 batteries in parallel to enhance power capacity. Additionally, connect multiple batteries in series-ensuring they are of the same type, capacity (Ah), and voltage (V) from the same brand. A battery balancer is recommended for extending service life when connecting batteries in series and/or parallel.
Reliable and Durable
The battery includes two premium copper terminal bolts for cable connections. Positive (+) and negative (-) icons are marked on the container for straightforward wiring identification.
Constructed with durable ABS container material, this battery is vibration-resistant and built to last.
To preserve the battery's cycle life, avoid discharging the battery below 10%.
For optimal performance and longevity, it is highly endorsed to utilize a battery that meets all specifications. balance to significantly extend the battery's service life, especially when multiple batteries are strategically connected in either series or parallel configurations.
For maximum efficiency and safety, we strongly advise installing the battery upright. Installation on its side is permissible solely for specific, justified reasons. However, under no circumstances should the battery be installed upside down. It is strongly advised to connect batteries of the same type (AGM), identical voltage (V), and uniform capacity (Ah), preferably from the same reputable brand, to ensure consistent performance.
| Normal capacity | Loading Power | Dimension(inch) | Weight(lbs) | Attended Mode | Bluetooth& Discharge Port | |
12.8v Lifepo4 | 7Ah | ≤100w | 5.94*2.55*3.70 | ≈1.77 | 4S1P | Customization |
| 10Ah | ≤100w | 5.94*3.89*3.70 | ≈3.75 | 4S1P | ||
| 12Ah | ≤200w | 5.94*3.89*3.70 | ≈3.08 | 4S2P | ||
| 15Ah | ≤300w | 7.12*3.03*6.61 | ≈4.19 | 4S1P | ||
| 20Ah | ≤300w | 6.49*4.96*6.89 | ≈6.61 | 4S1P | ||
| 25Ah | ≤350w | 6.49*4.96*6.89 | ≈6.83 | 4S1P | ||
| 30Ah | ≤400w | 6.85*6.49*4.92 | ≈7.94 | 4S5P | ||
| 50Ah | ≤500w | 7.79*6.53*6.69 | ≈12.8 | 4S1P | ||
| 100Ah | ≤1000w | 12.9*6.77*8.46 | ≈28.2 | 4S2P | ||
| 200Ah | ≤2000w | 20.6*9.45*8.58 | ≈55.1 | 4S4P | ||
| 300Ah | ≤3000w | 20.6*10.6*8.67 | ≈83.3 | 4S6P | ||
| 400Ah | ≤4000w | 20.6*10.6*8.67 | ≈110.2 | 4S8P |
Question 1: How long warranty you can provide for this lithium battery?
Answer: Normally 5 years according to the application.Lifepo4 cells with 3 year warranty. If there is any quality problem,we can send the new to replace it.
Question 2: What is the MOQ for the lithium battery?
Answer: There is no MOQ for samples. Big batteries MOQ is 50pcs, and small battery MOQ is 100ps.
Question 3: Do you accept OEM/ODM of our own brand and design?
Answer: Yes.
Question 4: Is this lithium ion battery safe compare with lead acid battery?
Answer: Lithium battery is much safer as it has BMS to prevent battery from over charging, over discharging, short circuit, high temperature etc.
Question 5: Can I replace the lead acid battery directly by lithium battery?
Answer: Yes, the lithium battery can be drop-in and plug-play replacement of original lead acid batteries.
Question 6: Would 2 100ah batteries be better or the same as 1 of the 200ah?
Answer: As far as capacity goes it's the same. However, 2 100 ah batteries would be better than 1 200 ah battery. This is because if anything ever happens to the 1 200 ah hour battery your screwed until you get another one. But, if anything ever happens to one of your 2 100 ah hour batteries, you at least have that second one you can run off of until you can get a new 100 ah battery. It always better to have a battery bank consisting of at least two batteries in case anything ever happens. You also have options of parallel connection or series connection for a 12 volt or 24 volt battery bank respectively. With just one battery, you get what you get.
Question 7:I am using 17k watt power per day. how many of this battery will I be needed for my power bank?
Answer:Dividing 17 kilowatt hours (kWh) by 12 volts I get 1417 amp hours. Batteries should be discharged to a maximum of 50% to provide reasonable service life. You would need 2834 amp hours of the rated capacity at 12 volts to operate and survive a couple years of the repeated discharge cycles. You need 15 of the 200Ah batteries (or 29 100Ah batteries.) Don't forget that you will also need to have approximately 20 kWh (1700Ah @ 12 volts) per day of charging capacity to accommodate battery storage and discharge inefficiencies.
