STMA material handling equipment narrow isle reach truck forklift with 3-way
electric reach forklift
Features of electric reach truck
--- Available in either DC or AC power options.
--- Convenient disassembly and replacement battery box.
--- Reducing weight, and prolonging the working life of the driving wheels.
--- Full hydraulic steering system, with integrative design of driving and steering, provides low-effort and flexible power steering.
--- Integrated driving and turning systems.
--- A fully hydraulic steering system ensures flexible turning, and requires less maintenance.
--- STMA electric reach trucks are designed to be efficient, quiet and provide a clean air environment.
--- Superior quality I beam and C channel construction creates a robust, rigid mast eliminating deflection for maximum durability and performance.
--- The hinged battery compartment cover is lightweight and easy to operate. The electrical control panel and related equipment is located inside the counterweight providing easy access and is protected from floor debris, contaminants and moisture.
--- Large grab handle and low step height allows easy operator access-egress to the operator's compartment. The premium suspension seat with fully adjustable forward, aft and lumbar positions allow added comfort for various sized operators. Forward right hand hydraulic control levers are ergonomically positioned for easy reach permitting one hand multi functions. Large floor space with common automotive pedal arrangement provides precise acceleration and braking performance.
| Electric Reach Forklift (Seated Type) 24V ERT-C | |||||
| 1.1 | Model No. | ERT12-C | ERT15-C | ERT20-C | |
| 1.2 | Power type | Electric | Electric | Electric | |
| 1.3 | Operation type | Seated type | seated type | seated type | |
| 1.4 | Load capacity | Q(kg) | 1200 | 1500 | 2000 |
| 1.5 | Load center | C(mm) | 500 | 500 | 500 |
| 1.6 | Front overhang | X(mm) | 180 | 180 | 180 |
| 1.7 | Wheelbase | Y(mm) | 1355 | 1355 | 1540 |
| 2.1 | Total weight with battery | kg | 1995 | 2180 | 2535 |
| 3.1 | Wheel type | PU | PU | PU | |
| 3.2 | Front wheel | ∅×w(mm) | 254*104 | 254*104 | 254*104 |
| 3.3 | Drive wheel | ∅×w(mm) | 230*75 | 230*75 | 230*75 |
| 3.4 | Balance wheel | ∅×w(mm) | 150*50 | 150*50 | 150*50 |
| 3.5 | Wheel tread,front wheel | b10(mm) | 976 | 976 | 976 |
| 3.6 | Wheel tread,rear wheel | b11(mm) | 772 | 772 | 772 |
| 4.1 | Mast lowered height | h1(mm) | 2120 | 2120 | 2120 |
| 4.2 | Lift height | h3(mm) | 4500 | 4500 | 4500 |
| 4.3 | Max.height when lifting | h4(mm) | 5485 | 5485 | 5485 |
| 4.4 | Height of overhead guards | h14(mm) | 2090 | 2090 | 2090 |
| 4.5 | Fork face min.ground clearance | h13(mm) | 35 | 35 | 40 |
| 4.6 | Fork tilting angle Front/rear | ° | 3/5 | 3/5 | 3/5 |
| 4.7 | Overall length | L(mm) | 2250 | 2250 | 2350 |
| 4.8 | Body length | l2(mm) | 1689 | 1689 | 1874 |
| 4.9 | Overall width | b1(mm) | 1090 | 1090 | 1090 |
| 4.10 | Fork size | s/e/l(mm) | 35/100/1070 | 35/100/1070 | 40/122/1070 |
| 4.11 | Fork adjustment size | b5(mm) | 210-705 | 210-705 | 210-705 |
| 4.12 | Reach distance | l4(mm) | 575 | 575 | 645 |
| 4.13 | Min.ground clearance | m2(mm) | 80 | 80 | 80 |
| 4.14 | Aisle Width for Pallet 1000*1200 Crossaway | Ast(mm) | 2764 | 2764 | 2872 |
| 4.15 | Min.turning radius | Wa(mm) | 1600 | 1600 | 1780 |
| 5.1 | Max. travel speed(unload/load) | km/h | 5/4 | 5/4 | 5/4 |
| 5.2 | Lifting speed(unload/load) | m/s | 0.135/0.115 | 0.135/0.110 | 0.135/0.100 |
| 5.3 | Lowering speed(unload/load) | m/s | 0.085/0.120 | 0.085/0.132 | 0.085/0.140 |
| 5.4 | Max.Grade ability(unload/load) | % | 8/6 | 8/6 | 8/6 |
| 5.5 | Brake type | Electromagnetism | Electromagnetism | Electromagnetism | |
| 6.1 | Driving motor | kw | 2.5 | 2.5 | 2.5 |
| 6.2 | Lifting motor | kw | 3 | 3 | 3 |
| 6.3 | Battery type | Lead Acid | Lead Acid | Lead Acid | |
| 6.4 | Battery capacity | V/Ah | 24V280Ah | 24V280Ah | 24V280Ah |
| 6.5 | Charger | V/Ah | 24V/40A | 24V/40A | 24V/40A |
| 7.1 | Drive controlling type | AC | AC | AC | |
| 7.2 | Noise level in driver's ear | dB(A) | 75 | 75 | 75 |
STMA Industrial(Xiamen) Co.,Ltd is a national high-tech enterprise specializing in the research development, production, sales and service of storage equipment and intelligent industrial vehicles, the company is located in a beautiful coastal city XIAMEN in China, It has advanced forklift manufacturing technology, perfect processing equipment and product testing center, and is a member of china industrial Vehicle Association, it has passed the safety production standardization, ISO9001 international quality system certification and EU CE certification, and has obtained nearly 50+ national invention patents, the main products are counterbalanced forklift truck(diesel forklift, gasoline forklift, electric forklift) and electric storage equipment such as pallet truck, stacker, reach truck, etc, are widely used in fields such as: automobiles, chemicals, products, electric applications, papermakig, medicine, beverages, clothing, logistics, e-commerce, and airport terminals.
Our company inherits the enterprise tenet of "honesty, customer first, quality first, timely delivery, service, whole staff participating, ceaseless improvement and pursuing excellence", and constantly develop new products to meet market demands, professional, high-quality, pioneering and energetic team, with a full range of skills, good reputation and professional ethics, to provide customers with comprehensive personalized service.
7*24HOURS SERVICE
******
Pre-Sales Service:
-- Inquiry and consulting support.
-- OEM Service available
-- Visit to our factory.
-- Photos&Videos for your order before shipment.
After-Sales Service
-- 1 year or 2000 working hours (which occurs first) period quality warranty , during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
-- Spare parts: STMA is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.
Q.What's the Certificate do you have?
A. STMA forklift meet with the ISO9001:2008 Quality System. All of our products with CE certificate. Some of our products meets the EPA requirements.
Q. What are our advantages compared with other manufactures/factories?
A.1) Reliable Quality: Carefully select regular manufacturers for supporting spare parts, like engines, bridge,transmissions, and many parts designed and produced by ourselves, always adapting the best materials
A.2) Fast Delivery: Generally, we can delivery within 10 working days in factory after receiving pre-payment from customers.
Q. Which payment terms can we accept?
A. Normally we can work on T/T or L/C.
A.1) On T/T term, 30% payment is required in advance for production, 70% balance shall be paid before delivery or againes the copy of original B/L for old long cooperation clients.
A.2) On L/C term, 100% irrevocable LC at sight without "soft clauses" can be accepted.
Q. Can we provide OEM SERVICE?
A. STMA can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
