HSG-B500E1
Single Girder Crane
Wire Rope
CE, ISO9001:2000
New
100% Copper
300kg
Lifting
100% Copper
Under Slewing Cranes
Double Girder
Electric
Wheel
Assembled
KAIXUN
Carton
CE
China
84253100
Product Description
Features
1. Handle control voltage 24VAC
2. With IP65 protection degree
3. Working rate is S3-40%, 20min
4. It can be used for mine lifting,
5. insulation degree is B.
6. protection degree is IP54.
7. With thermal prevention Device.
8. Working rate is 40%, 20min
Technical Parameters
| Model | HSG-B300 | HSG-B400 | HSG-B500 | HSG-B300E1 | HSG-B400E1 | HSG-B500E1 | |
| Rated Load | Kg | 300 | 400 | 500 | 300 | 400 | 500 |
| Lifting Height | m | 24 | |||||
| Lifting Speed | m/min | 21 | 21 | 16 | 28 | 21 | 21 |
| Cable Diameter | mm | 6 | 6 | 7 | 6 | 6 | 7 |
| Power Source | V | AC 100/110/120220/230/240 | 3 phase AC 220/380/420/440 | ||||
| Frequency | Hz | 50/60 | |||||
| Packing Size | mm | 800 × 340 × 540 | |||||
| G. W. /N. W. | Kg | 57/55 | 57/55 | 60/58 | 57/55 | 57/55 | 60/58 |
Company Profile
Kaixun Group --- Zhejiang Kaixun Mechanical and Electrical Co., Ltd., which founded in 1998, is an export-oriented high-tech enterprise. We integrate R&D, production and sales into one body, and we are specialized in manufacturing various 380 items, including hoisting macchinery, financial equipments, electric winch, wlwctric truck, electric forklift and hydraulic car, etc.
Our comapny locates at Wenzhou City, Zhejiang Province, China. We covers an area of 59000m², structure area 87000m², and owned 880 sets of production equipment, which includes 260 sets of testing instruments. We have the ability of output RMB1500 million every year.
We aim to set up KAIXUN brand, creat top quality, offrt brst service and ensure customer satisfactory. We have passed the certification of ISO9001:2008 quality system. Many products have got CE, GS, RoHS, CB, UL, CUL, and FCC approvals.
Now we have been exporting 90% of our products in bulk to Europe, USA, Africa, Middle east, south Asia, Russia, India, etc. Over 120 countries and regions. Our products are highly praiised by our clients.
