FD25/FD30/FD35
Online
15 Months
Adjustable
Container Forklift
Diesel Engine
1T - 5T
Diesel
>500mm
New
China / Japan for Choice
Duplex/Full Free Lift Mast
LED Light, Lux Seat, Fan, Solid Tire Ect
Automatic Transmission
Side Shifter, Clamps, Positioner Ect
Pneumatic Tire
Cumtomer Cutomized
Yes
SNSC
Container Shipment
4250kg
China, Wuhu
84272090
Product Description
Gura horquilla Forklift 2Ton 3Ton 3.5Ton Diesel Gura horquilla Forklift Gura horquilla Forklift
Gura horquilla Forklift 2Ton 3Ton 3.5Ton Diesel Gura horquilla Forklift Gura horquilla Forklift
| No. | Specifications | Unit | FD20E | FD25E | FD30E | FD33E | FD35E | FD40E | |||
| 1 | 1 | Characteristics | Power | diesel | diesel | diesel | diesel | diesel | diesel | ||
| 2 | 2 | Rated Capacity | kg | 2000 | 2500 | 3000 | 3300 | 3500 | 4000 | ||
| 3 | 3 | Center of load | mm | 500 | 500 | 500 | 500 | 500 | 500 | ||
| 4 | 4 | Lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | ||
| 5 | 5 | Free lifting height | mm | 135 | 135 | 145 | 145 | 85 | |||
| 6 | 6 | Forks L×W×H | mm | 1070x122x40 | 1070x122x40 | 1070x125x45 | 1220x125x45 | 1070x125x45 | 1070x125x50 | ||
| 7 | 7 | Tilt Forward/Backward | . | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | ||
| 8 | 8 | Min.turning radius | mm | 2240 | 2240 | 2400 | 2445 | 2445 | 2700 | ||
| 9 | 9 | Min.ground clearance(Mast) | mm | 110 | 110 | 110 | 110 | 110 | 120 | ||
| 10 | 10 | Overhead guard height | mm | 2120 | 2120 | 2138 | 2138 | 2138 | 2090 | ||
| 11 | 11 | Height from seat to overhead guard | mm | 943 | 943 | 943 | 943 | 943 | 1005 | ||
| 12 | 12 | Front overhang | mm | 473 | 473 | 483 | 483 | 483 | 500 | ||
| 13 | 13 | Perf | Max.traveling speed(loaded) | km/h | 19 | 19 | 20 | 20 | 20 | 19.5 | |
| 14 | 14 | Max.lifting speed(loaded/empty) | mm/s | 470/510 | 470/510 | 470/520 | 470/520 | 470/520 | 415/440 | ||
| 15 | 15 | Drawbar pull/Gradeability | kN/% | 17/20 | 17/20 | 18/20 | 18/20 | 18/20 | 20/20 | ||
| 16 | 16 | Dimensions | Overall length (without fork) | mm | 2570 | 2570 | 2695 | 2745 | 2700 | 2930 | |
| 17 | 17 | Overall width | mm | 1175 | 1175 | 1230 | 1230 | 1230 | 1410 | ||
| 18 | 18 | Mast lowered height | mm | 1990 | 1990 | 2055 | 2645 | 2055 | 2155 | ||
| 19 | 19 | Mast extended height | mm | 4000 | 4000 | 4256 | 4255 | 4255 | 4275 | ||
| 20 | 20 | Chassis | Tire | Front | 7.00-12-12PR | 7.00-12-12PR | 28x9-15-12PR | 28x9-15-12PR | 28x9-15-12PR | 250-15-160PR | |
| 21 | 21 | Rear | 6.00-9-10PR | 6.00-9-10PR | 6.50-10-10PR | 6.50-10-10PR | 6.50-10-10PR | 6.50-10-10PR | |||
| 22 | 22 | Wheelbase | mm | 1600 | 1600 | 1700 | 1700 | 1700 | 1900 | ||
| 23 | 23 | Tread width | Front/Rear | mm | 970/970 | 970/970 | 1000/970 | 1000/970 | 1000/970 | 1160/1065 | |
| 24 | 24 | Curb weight | None-load | kg | 3350 | 3750 | 4350 | 4850 | 4850 | 5300 | |
| 25 | 25 | Powertrain | Battery | Voltage/Capacity | V/Ah | 12/90 | 12/90 | 12/90 | 12/90 | 12/90 | 12/90 |
| 26 | 26 | Engine | Model | XC490BPG | XC490BPG | XC490BPG | XC490BPG | XC495BPG | XC498BPG | ||
| 27 | 27 | Rated power | kw/r.p.m | 37/2650 | 37/2650 | 37/2650 | 37/2650 | 42/2650 | 45/2500 | ||
| 28 | 28 | Rated torque | Nm/r.p.m | 148/2000 | 148/2000 | 148/2000 | 148/2000 | 174/2000 | 193/1600-1800 | ||
| 29 | 29 | Cylinder amount | 4 | 4 | 4 | 4 | 4 | 4 | |||
| 30 | 30 | Bore×Stroke | mm | 90x100 | 90x100 | 90x100 | 90x100 | 95x105 | 98x105 | ||
| 31 | 31 | Displacement | 2.54 | 2.54 | 2.54 | 2.54 | 2.98 | 3.168 | |||
| 32 | 32 | Fuel tank | L | 60 | 60 | 70 | 70 | 70 | 80 | ||
| 33 | 33 | Transmission | 1/1 automatic transmission | ||||||||
| 34 | 34 | Working pressure | MPa | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | ||
| Engine | China xinchai engine/Japan Mitsubishi & iszu engine |
| Transmission | Auto/manual hand/machinery |
| Lifting height | 3000-6000mm |
| Mast | Standard duplex/Duples full free lift/Triplex full free lift |
| Tire | Pneumatic tire/solid tire/double front tire/off road tire Gura horquilla Forklift Gura horquilla Forklift Gura horquilla |
| Overhead guard | Gird type/water-proof type Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Light | front lamp/rear lamp/truning linght/combination light Gura horquilla Forklift Gura horquilla Forklift Gura horquilla |
| Mirror | Left and right mirror/Rearview mirror/wide view mirror Gura horquilla Forklift Gura horquilla Forklift Gura horquilla |
| Seat | Standard seat/ seat with belt/seat with arm/suspension seat |
| Fork length | 920mm/1070mm/1220mm/1570mm ect. Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Color | Green/yellow/red/customer customized. Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Certificat | CE &ISO &EPA |
| Tool box | Yes Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Maintenance manual | Yes Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Operation manual | Yes Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Spare part manual | Yes Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
| Free Spare part | Yes Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift |
Our forklift used standard 1070mm fork length. We can offer all kinds attachment according customers' working condition, eg : solid tire/ side shifter/ positioned/paper roll clamp/carton clamp/block clamp/bale clamp/positioner ect.
SNSC Forklift have strict indoor and outdoor quality control system which includes braking performance, the inclination angle of the mast, detection of chassis oil leakage, counterweight, loading, lifting, tilting, turning, climbing, etc.
Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
To ensure our customers can receive high performance forklifts, all of our forklifts will be tested again before delivery. If not passed any test, the forklift is not allowed leave from our factory. If the storage time exceeds 1 month, we need to do regular maintenance and testing until it leaves the factory.Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
We have all kinds of forklift, here is our forklift catalogue for your choice:
1)Diesel forklift truck capacity from 1.5ton to 32ton; Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
2) Electric forklift truck capacity from 1.5ton to 12ton;Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura
3) LPG gas gasoline forklift truck capacity from 1.5ton to 7ton;Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
4) Warehouse equipment, includes electric pallet truck, electric reach truck, electric stacker, electric trailer
5) Rough terrain forklift truck capacity from 1.8-5ton;Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
6) Other special function forklift, eg: cold warehouse electric forklift, explosion-proof forklift, VNA Articulated forklift, Multi-directional forklift,telehandler forklift,self propelled boom lift ect Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift Gura horquilla Forklift
