FUPIA Double deep reach truck is designed to allow double-deep pallet storage in the racks for increased storage density.It features a stronger mast, higher reach, and narrow footprint; allowing you to make the most of your storage space.
- Rugged steel structure with high precision mast enhance the good performance in stabilities and safety.
- Unmatched comfort, control, and safety enable operators to perform with confidence, all shift long.
-Durability, energy efficiency, and ease of maintenance minimise downtime to keep the reach truck running strong for maximum productivity.
- Compact design with small turning radius to give excellent manoeuvre.
- The opened overhead guard design offers unmatched, all-around visibility - at ground level, eye level, height and in all directions around the operator.
- The hydraulic scissors-type mechanism makes it easier to pick up the load and retract it automatically and smoothly.
- Adopting Italy ZAPI or USA Curtis AC controller with microprocessor control system brings high performance to the operator due to higher motor torque and energy efficiency. Full AC motors ensure enhanced performance and reliability, while Electromagnetic braking offers an advantage in performance, service and total cost of ownership by virtually eliminating brake maintenance.
| General | 1 | Brand | FUPIA | |
| 2 | Model | FBK15 | ||
| 3 | Power Type | Battery | ||
| 4 | Rated Load Capacity | Q(kg) | 1500 | |
| 5 | Load Centre | C(mm) | 500 | |
| Characteristic & Dimension | 6 | Rated Lift Height | H3(mm) | 6000 |
| 7 | Free Lift Height | H2(mm) | 200 | |
| 8 | Fork Size (L×W×T) | mm | 920×120×35 | |
| 9 | Mast Tilt Angle (F α°/β°) | deg | 3/5 | |
| 10 | Length to Face of Fork (Without Fork) | L1(mm) | 2752 | |
| 11 | Overall Width | B1(mm) | 1450 | |
| 12 | Mast Lowered Height | H1(mm) | 2950 | |
| 13 | Mast Extended Height (With Backrest) | H4(mm) | 7045 | |
| 14 | Overhead Guard Height | H5(mm) | 2205 | |
| 15 | Turning Radius (Outside) | Wa(mm) | 2070 | |
| Performance | 16 | Travel Speed (No Load) | km/h | 9.5 |
| 17 | Travel Speed (Full Load) | km/h | 9 | |
| 18 | Lifting Speed (Full Load/No load) | mm/sec | 240/360 | |
| Chassis | 19 | Tyre (Front x 2) | mm | 125x75x4 |
| 20 | Tyre (Rear x 1) | mm | 343x135 | |
| Power & Drive | 21 | Battery | V/Ah | 48/420 |
| 22 | Drive motor | Kw | 6 | |
| 23 | Lift motor | Kw | 11 | |
| 24 | Steering system | Electronic | ||
| 25 | Service brake | Electromagnetic | ||
| 26 | Control type | AC | ||
| 27 | Controller manufacturer | ZAPI/CURTIS | ||
| 28 | Operating Pressure (For Attachments) | Mpa | 16 |
