15583-80201
Aluminum Alloy
Polishing
Non-Customized
Standard
Forklift Inching Valve
15583-80201
Heli Lifter 1-3t
High Quality Forklift Aftermarket Parts
Leading forklift parts
Corrugated Carton with Plywood Case
28*12*9 cm
China
8412800090
Product Description
Product Title: Forklift Inching Valve
Product Model: 15583-80201 for CPCD30 Lift Trucks
Here are other forklift inching valves below for your choice:
Feature of Forklift Inching Valve
Application of Forklift Inching Valve
This forklift hydraulic inching valve is widely applied to a 3T internal-combustion forklift automatic hydraulic transmission box to control the clutch slowly on and off. Regular customers: TCM, HELI, HANGCHA, Lonking, etc.
Specification of forklift transmission inching valve
Product Model: 15583-80201 for CPCD30 Lift Trucks
| Item | Description |
| Product Name | Forklift Inching Valve |
| P/N | 15583-80201 YDS30.903 |
| Applied Model | HELI Lifter 1-3T, Hangcha CPCD30 Forklift |
| Net Weight (kg) | 2.7 |
| Gross Weight (kg) | 3 |
| Qty per Carton | 1 |
| Carton Size (cm) | 28*12*9 |
Here are other forklift inching valves below for your choice:
Feature of Forklift Inching Valve
- WD-A8G forklift inching valve is installed on the transmission, joined together with a clutch pedal, by controlling the pressure of the clutch to make it on or off
- When pushing on the pedal, the forklift inching valve stem stretches, so the clutch is on.
- When releasing the pedal, the forklift inching valve stem rebound, so the clutch is off
- When the stroke of the clutch pedal is between 2-6.5mm, the pressure of the clutch is reduced slowly, so the forklift is moving slowly
- The forklift inching valve has a superior alloy steel stem with high strong anti-abrasion cast iron body for a long service life
- All valve holes and oil passages of the forklift inching valve were made by the machining center for geometric tolerance precision
- forklift inching valve is applied with double O sealing
Application of Forklift Inching Valve
This forklift hydraulic inching valve is widely applied to a 3T internal-combustion forklift automatic hydraulic transmission box to control the clutch slowly on and off. Regular customers: TCM, HELI, HANGCHA, Lonking, etc.
Specification of forklift transmission inching valve
| Item | Parameter |
| Pressure (MPa) | 0-1.4 |
| 12mm Shift force (N) | 121 |
| Inching valve stroke (mm) | 25 |
| Weight (Kg) | 2.1 |
