Product Description
Company Profile
TXK was founded in 1997 with 1.5 million USD registered fund in the very beginning and grow up as a leading manufacturer of electric chain hoist, manual chain hoist, electric wire rope hoist and various lifting and material handling equipments with more than 15 years experience and hard work.Our factory cover an area of 66000 square meters, the biggest workshop in the electric hoist industry in China.
Our products are widely used in industry and manufacturing industry and other special purpose, such as mold, wind power, logistics, railway, shipbuilding, bridge construction, factory assembly line, mechanical maintenance platform etc.
The electric wire rope hoist CD1 and MD1 have features of compact, light, small-sized shape and smooth operation. It can be uesd not only on the overhead reils, but also be uesd in conjunction with many types of electric or manual cranes such as the single-grider crane, the double-grider crane, the cantilever crane and the gantry crane. The eletric hoist model MD1 with double lifting speeds should be used in case where the hiost model CD1 can not meet the requirements for fine abjustments during precision operations
Workshop :
Packing
Exhibitions
The company establishes a global marketing network with exportation to Germany, Norway, Poland, United States, Canada, Mexico, Peru, Brazil, Argentina, Egypt, Saudi Arabia, South Africa, India, Indonesia, Malaysia and total more than 50 countries and regions
Cerificates
We provide quality, safe and stable products to meet the highest industrial standards. We are ISO9001: 2008 and TUV certified manufacturer, our products are CE, GS, SGS certified, serving all spheres of industry in the world.
Other lifting equipments:
Jib crane ,Overhead Crane
TXK was founded in 1997 with 1.5 million USD registered fund in the very beginning and grow up as a leading manufacturer of electric chain hoist, manual chain hoist, electric wire rope hoist and various lifting and material handling equipments with more than 15 years experience and hard work.Our factory cover an area of 66000 square meters, the biggest workshop in the electric hoist industry in China.
Our products are widely used in industry and manufacturing industry and other special purpose, such as mold, wind power, logistics, railway, shipbuilding, bridge construction, factory assembly line, mechanical maintenance platform etc.
The electric wire rope hoist CD1 and MD1 have features of compact, light, small-sized shape and smooth operation. It can be uesd not only on the overhead reils, but also be uesd in conjunction with many types of electric or manual cranes such as the single-grider crane, the double-grider crane, the cantilever crane and the gantry crane. The eletric hoist model MD1 with double lifting speeds should be used in case where the hiost model CD1 can not meet the requirements for fine abjustments during precision operations
Parameters
| capacity | 2t | ||||||||
| Lifting Height | m | 6 | 9 | 12 | 18 | 24 | 30 | ||
| Lifting Speed | m/min | 8(8/0.8) | |||||||
| Travelling Speed | m/min | 20 | |||||||
| Orbit | I-Beam | 20a-32c | |||||||
| Mini Radius Curvature | m | 1.8 | 2 | 2.5 | 3.5 | ||||
| Power of Main Motor | Kw | 3(3/0.4) | |||||||
| Power of Traveling Motor | Kw | 0.4 | |||||||
| Basic Size | Hook Suspension | L | mm | 820 | 920 | 1020 | 1220 | 1420 | 1620 |
| L(MD1) | mm | 830 | 865 | 965 | 1160 | 1355 | 1550 | ||
| L1 | mm | 418 | 518 | 618 | 818 | 1018 | 1218 | ||
| f1 | mm | 770 | |||||||
| B1 | mm | 240 | |||||||
| Φ | mm | 4-Φ 23 | |||||||
| h | mm | 155 | |||||||
| f | mm | 856 | 956 | ||||||
| Bmax | mm | 935 | |||||||
| Total Weight + 10% | CD1 Hook Suspension | mm | 174 | 190 | 208 | 232 | 260 | 284 | |
| CD1 Trolley Type | kg | 230 | 244 | 299 | 315 | 337 | 357 | ||
| MD1 Hook Suspension | kg | 184 | 200 | 218 | 242 | 270 | 294 | ||
| MD1 Trolley Type | kg | 269 | 284 | 335 | 369 | 379 | 404 | ||
Workshop :
Packing
ExhibitionsThe company establishes a global marketing network with exportation to Germany, Norway, Poland, United States, Canada, Mexico, Peru, Brazil, Argentina, Egypt, Saudi Arabia, South Africa, India, Indonesia, Malaysia and total more than 50 countries and regions
CerificatesWe provide quality, safe and stable products to meet the highest industrial standards. We are ISO9001: 2008 and TUV certified manufacturer, our products are CE, GS, SGS certified, serving all spheres of industry in the world.
Other lifting equipments:
Jib crane ,Overhead Crane
