YF-TDN08Z
351-500W
36V
Lithium Battery
20"
Brushless
Aluminum Alloy
CE, EN15194
Folded
20-40km/h
31-60km
Battery:Sumsung 10.4ah
YiFEi
Carton
145*26*65cm
Jinhua
8711901010
Product Description
Now, let's get familiar with our NEW electric bikes as below:
Model : TDN08Z
Certification : CE
1. Ergonomic and soft, Same color with handle grip
2. Aluminum handle bar & stem
3. TGS aluminum front fork
4. Integrated wheel
5. Front and Rear Tektro disc brake
6. Kenda tire 20inchX2.125
7. Internal lithium battery 36V/9AH capacity
8. Aluminum frame folder
9. Promax suspension aluminum seat post
10. Aluminum rear rack,sole design for assembling baby seat
11. 52T big crank, laborsaving when pedal
12. Wellgo brand foldable pedal
13. Aluminum middle kickstand
14. KMC stainless chain
Model : TDN08Z
Certification : CE
1. Ergonomic and soft, Same color with handle grip
2. Aluminum handle bar & stem
3. TGS aluminum front fork
4. Integrated wheel
5. Front and Rear Tektro disc brake
6. Kenda tire 20inchX2.125
7. Internal lithium battery 36V/9AH capacity
8. Aluminum frame folder
9. Promax suspension aluminum seat post
10. Aluminum rear rack,sole design for assembling baby seat
11. 52T big crank, laborsaving when pedal
12. Wellgo brand foldable pedal
13. Aluminum middle kickstand
14. KMC stainless chain
| Specifications----TDN08Z | |
| Frame | 6061#Aluminum alloy |
| Motor | Rear brushless hub motor 36V/250W |
| Battery | 36V/9AH Internal lithium battery |
| Charger | AC 110V-240V |
| Displayer | Digital LCD 0-9 levels PAS speed |
| Brake lever | Wuxing brand,power cut-off automatically when braking |
| Front fork | ZOOM brand, Aluminium with suspension |
| Light | Spanniga LED |
| Handle stem | Aluminium Standard |
| Transmission | SHIMANO 6 gears; derailleur protector included |
| Saddle | VELO brand Ergonomic and soft |
| Saddle post | Unfoldable & Unsuspension |
| Tire | KENDA 20*2.125 |
| Mudguard | PVC in aluminum black |
| Rim | Double wall Aluminium |
| Spoke | Integrated wheel |
| Crank | Aluminium alloy 52T |
| Pedal | Wellgo foldable |
| Rear rack | Aluminium |
| Brake | F/R Disc brake |
| Chain and spokes | KMC brand chain,stainless steel spokes |
| Parameters: | |
| Max Speed : 25km/h(EU),32km/h(US & CA) | |
| Mileage per charge : >50km/charge | |
| Charge time : 4-6H | |
| Charge life : >=500times | |
| Loading capacity: 120KGS | |
| Carton size: 145*26*68cm | |
| N. W/G.W : 25kg/29 kg, battery included | |
| Container loading: 20"FCL 110pcs / 40"FCL 270pcs | |
