| 1.1 | Manufacturer | VLIFT | |
| 1.2 | Model designation | VQD15SS | |
| 1.3 | Drive unit | Battery | |
| 1.4 | Operator type | Standing | |
| 1.5 | Load capacity | Q (kg) | 1300 |
| 1.6 | Load center distance | c (mm) | 550 |
| Weights | |||
| 2.1 | Service weight | kg | 2450 |
| Wheels, Chassis | |||
| 3.1 | Tyre type | PU | |
| 3.2 | Tyre size, driving wheels | (mm) | 343*135 |
| 3.3 | Tyre size, loading wheels | (mm) | 180*76 |
| 3.4 | Tyre size, ballance wheels | (mm) | 180*76 |
| Dimensions | |||
| 4.1 | Mast/ fork carriage tilt, forward/ backward | α/ β (°) | 2/ 4 |
| 4.2 | Height, mast lowered | (mm) | 1960 |
| 4.3 | Lift height | (mm) | 4000 |
| 4.4 | Height, mast extended | (mm) | 4760 |
| 4.5 | Overall length | (mm) | 2850 |
| 4.6 | Length to face of forks | (mm) | 1280 |
| 4.7 | Overall width | (mm) | 1520 |
| 4.8 | Fork dimensions | (mm) | 40×120×1070 |
| 4.9 | Distance between fork-arms | (mm) | 260-700 |
| 4.10 | Reach distance | (mm) | 1000 |
| 4.11 | Ground clearance, laden, below mast | (mm) | 40 |
| 4.12 | Overhead guard height | (mm) | 2260 |
| 4.13 | Aisle width, 1000×1200 pallet crossways | (mm) | 3200 |
| 4.14 | Turning radius | (mm) | 1930 |
| Performance | |||
| 5.1 | Travel speed, laden/ unladen | km/ h | 7.5/ 8.0 |
| 5.2 | Lifting speed, laden/ unladen | m/ s | 130/220 |
| 5.3 | Max.gradeability, laden/ unladen | % | 5/7 |
| 5.4 | Service brake | Electromagnetic | |
| Drive | |||
| 6.1 | Drive motor rating S2 60 min. | kW | 6.3 |
| 6.2 | Lift motor rating at S3 15% | kW | 4.5 |
| 6.3 | Battery voltage/ rated capacity (5h) | V/ Ah | 48/300 |
| Others | |||
| 7.1 | Type of drive control | AC | |
| 7.2 | Travel speed control mode | Hall accelerator | |
| 7.3 | Braking mode | Electromagnetic brake | |
| 7.4 | Steering mode | Electric steering | |
According to the delivery requirements of each customer, we carefully package each TRUCK. Before delivery, we will take photos and videos, and only after getting the customer's approval will we send them away.
We got CE certificate for material handling equipment of Manual Lift Trucks and Electric Lifting Trucks.
Company introduction:
Shanghai Vlift Equipment Co., Ltd. is one of the leading suppliers of diesel forklifts, gasoline/LPG forklifts, electric forklift, electric pallet trucks, electric stackers, manual pallet trucks, manual stackers, oil drum carriers, container ramps, work platforms, and lift tables. Vlift aims at provide you high quality, high performance material handling equipment. Everywhere in the world you can see products made in China, and Vlift has the responsibility to offer you the satisfactory equipments at good price.
OEM and ODM
We provide you with the service of making your company logo, nameplate, etc. free of charge and accept all orders OED and ODM based on a certain quantity.
Delivery lead time
our lead times are usually within 3-15 days, except for customised products and products with shortage of parts.
Customs clearance matters
We provide you with complete customs clearance documents, upon your request, can provide you with various commercial certifications based on the products ordered.
About after-sales service
1) Operation Manual and parts manual:
We provide you with detailed and professional English manual and parts manual, including paper and electronic versions, with detailed pictures so that you can understand the various parts of the product at a glance.
2) After-sales support:
We provide after-sales support with a minimum response time of one hour, and our after-sales team provides you with comprehensive guidance in the form of text, telephone and video.
3)Accessory supply:
except for some perishable parts, all other products and parts sold by us are guaranteed for 1 year or 2000 hours; parts beyond the warranty period will be provided to you at a 20% discount from the market price.
