ZTCH-5.0ZG
on Line After-Service
Combine Harvester
Cotton, Rice, Corn, Fruit, Wheat, Soybean, Tubers, Straw
Diesel
Vibration fall
Gear Drive
Soft Shaft
Backpack Type
QS, GMP, ISO9001:2008, CE
Red
New
Agriculture, Livestock, Aquaculture, Forestry
1 Year
5750*2440*3040
2440 mm
1 Year
500*90*54mm
High Productivity
50 - 120 HP
2600r/Min
Provided
3
Combine Harvester
4D35r41s1106
3420 Kg
Provided
New Product 2020
CE
TDER
Container Shipment
5750*2440*3040mm
Fujian, China
Product Description
Model | 4LZ-50.ZG Combine Harvester | ||
Overall Dimension Length×Width×Heights(mm): | 5750×2440×3040 | ||
Weight (kg) | 3420 | ||
Engine | Engine Model | 4D35R41S1106 | |
Rated Power(kw/hp) | 81.5KW | ||
Engine Type | Water-Cooled,4-Cylinder,Dl-Injection,Vertical Turbocharged Diesel | ||
Rated Rotation Speed (r/min) | 2600 | ||
Traveling System | Type of Gearbox: | Hydraulic type +HST(3F,3R) | |
Rubber Track(mm) | 500×90×54 | ||
Gauge | 1250 | ||
Minimum Ground Clearance (mm) | 320 | ||
Cutting header | Height Adjustment | Hydaulics. | |
Cutting Width(mm) | 2100 | ||
Header auger type | Telescopic Screw Conveying | ||
*Please contact us if you need more detailed parameters.
1.Using small spike-tooth structure shear flow, rice harvesting effect;
2.Using the longitudinal axial flow narrative structure, the story effect is better;
3.Adopting the miscellaneous return structure, the structure is reduced, and the cleaning effect is better!
4.Better results in wheat, soybeans, corn, etc.
5.The header adopts a quick hook structure, which is convenient, light and reliable;
6.The use of extended grain unloading drum makes it easy to unload grain;
7.The roller chopper mechanism is adopted, which can better meet the agronomic
requirements
8.Use left and right energy tanks (236 liters) to effectively reduce the frequency of refueling.
Founded in 2003, TDER Group is an international large-scale machinery manufacturing company, engaged in the invention and sales of various machinery products, including forklifts, loaders, warehouse equipment and port equipment. The TDER Group has established 3 factories. All 25 categories of products have passed the SGC, TUV, BV, INTERTEK and other authoritative international institutions certification. Today, our products have been exported to Brazil, Russia, Australia, Canada, Turkey and other 158 countries and regions, with 56 agents.
