2. Low Consumption: Standby State power less then 3w, saving energy.
3. LED indicator light, check the charging information clearly.
| Datasheet | Parameters | |
| Appearance structure | Item NO. | AC Type1 16A 1.92KW Display Screen Portable EV Charger |
| Model | Plug&Play/Book time/Current adjustable | |
| Enclosure | Charging gun-Control box PC9330 | |
| Installation Method | Portable/Wall-mounted | |
| Install Components | Screw | |
| Power Direction | Input(Up)&Output(Down) | |
| Cable Size | 3*2.5mm²+0.75mm² | |
| Cable Length | 5M or Negotiation | |
| Size | Charging Gun230*98*58mm/Control Box220*80*70mm(H*W*D) | |
| Electrical index | Power Supply | 1Phase |
| InputVoltage | AC120V | |
| InputFrequency | 50-60Hz | |
| MaxPower | 1.92KW | |
| OutputVoltage | AC120V | |
| OutputCurrent | 16A | |
| StandbyPower | 3W | |
| Environment index | Applicablescene | Indoor or Outdoor |
| WorkHumidity | 5%~95%(non-condensing) | |
| WorkTemperature | -30ºC~+50ºC | |
| WorkAltitude | <2000M | |
| ProtectionClass | IP67 | |
| CoolingMethod | Natural Cooling | |
| Standard | SAEJ1772 | |
| Flammabilityrating | UL94V0 | |
| Certificate | UL,TUV,CE,RoHS,CB | |
| Functional design | Interface | LED Indicator Light |
| Communication | / | |
| safety design | Over Current Protection,Residual Current Protection,Ground Protection,Surge Protection,Over/Under Voltage,Frequency,Temperature Protection | |
| Packaging specification | L*W*H:410*410*125mm (About 3KG) | |
| Click here to visit our store & see more products |
Ningbo Jadelight New Energy Technology CO.,LTD is an industrial and trade company,is an enterprise engaged in science and technology promotion and application service industry.We are an international trading company and have our own production plant.
Main projects: AC DC charging products of electric vehicles,such as portable EV Charger,smart EV wallbox,EV charging station,EV charging pile,EV charger adapter,EV plug connector,EV charging cable and so on. Our products have comprehensive quality certifications including CE, RoHS, TUV,CB,UL, FCC,etc which can meet the standards of all target markets.
Products are exported all around the world more than 60 countries, including United States,Europe,South Africa,Middle East market, Southeast Asia, etc.
We also offer OEM ODM custom services. We guarantee high quality and provide excellent after-sales service. Our values are cooperation, innovation,quality and win-win.
Wish to become your best supplier.
