- Separately wired from electricity meter, start charging when the car connected to the charging station.
- When the device is in standby mode, the power is as low as 3W, saving energy and low consumption.
- Applicable to 99% new energy vehicle on the market.
- LED charging indicator light, indicating charging related value.
| Model NO | JL-GBT223 | |
| Appearance Structure | Product name | 32A 7KW RFID Display Screen EV Charger |
| Product type | Swipe card activation | |
| Shell material | Gun head PC9330,Control Box ABS,Glass Panels | |
| Size | Gun head 230*98*58mm/ control box 368*228*100mm(H*W*D) | |
| Installation type | Floor standing/wall mounted | |
| Install components | Column (Option) | |
| Wiring method | Down in and down out | |
| Weight | 4 . 6 5 K G | |
| Cable specification | 3 * 6 mm ² + 0 . 7 5 mm ² | |
| Cable length | 5meters | |
| Electrical Specifications | Input voltage | A C 2 2 0 V |
| Input Frequency | 50Hz | |
| Max power | 7 K W | |
| Output voltage | A C 2 2 0 V | |
| Output current | 32A | |
| Stand-by power | 3W | |
| Environment Pointer | Applicable scenarios | Indoor/Outdoor |
| Relative humidity | 5%~95% | |
| Working temperature | -30ºC~+50ºC | |
| Working altitude | <2000 meters | |
| Protection class | Gun head IP67/ control box IP54 | |
| Cooling mode | Natural Convection cooling | |
| Safety standard | GB/T 20234.1/2-2015 | |
| Functional Design | Human Interface | Display Screen,LED indicator light |
| Communication Interface | / | |
| Package Specification | Box size/weight | L*W*H: 460*300*250mm(5.5KG) |
| Safety Design | Undervoltage protection,Overvoltage protection,Overload protection,Overcurrent protection,Over temperature protection,Leakage protection,Grounding protection,Lightning protection,Electrostatic protection,Flame retardant protection | |
NINGBO JADE LIGHT NEW ENERGY TECHNOLOGY CO.,LTD
Ningbo Jadelight New Energy Technology CO.,LTD is an industrial and trade company,is an enterprise engaged in science and technology promotion and application service industry.We are an international trading company and have our own production plant.
Main projects: AC DC charging products of electric vehicles,such as portable EV Charger,smart EV wallbox,EV charging station,EV charging pile,EV charger adapter,EV plug connector,EV charging cable and so on. Our products have comprehensive quality certifications including CE, RoHS, TUV,CB,UL, FCC,etc which can meet the standards of all target markets.
Products are exported all around the world more than 60 countries,including United States,Europe,South Africa,Middle East market, Southeast Asia, etc.
We also offer OEM ODM custom services. We will provide quality products and after-sale service. Our values are cooperation,innovation,quality and win-win.
Wish to become your best supplier.
