| Control Method | Auto Control |
| Max Capacity | 17~440p |
| Rated Capacity | 15~440 Persons |
| Peak Load | 149~3850L/H |
| Electricity | 380V50Hz/415V50Hz/440V60Hz |
| STP Standard | Imo Mepc.227(64) |
| Certificate | CCS, EC |
| Origin | China |
This plant is applicable to treat the sewage, which means human body wastes and the wastes from the toilets on vessels and which is also called "black water", to meet the effluent standards of and discharge the effluent to overboard. It is also applicable to treat galley & shower drainage which is called "grey water" on condition that the "grey water" should be pretreated and should select a bigger capacity model to match with.
Marine Sewage Treatment Plant belongs to the key devices for prevention of pollution form ships in seas and oceans according to the revised Annex IV of the International Convention of the Prevention of Pollution (MARPOL 73/78). The MEPC. 2 (VI) resolution adopted on 3 December 1976 is the present guidelines on implementation of effluent standards and performance tests for STP, which is called "old standards". This device is according to the MEPC. 159(55) resolution enacted on 13 October 2006, which is called "new standards". The convention (MARPOL 73/78) provides that all STPs installed on board on or after 1 January 2010 should meet the MEPC. 159(55) resolution.
Standard :Meet the requirement of New standard IMO MEPC. 159(55),MARPOL 73/78). MEPC. 2 (VI)
Certificate : CCS , EC
Capacity : 15- 440 persons
Usage : treat the sewage , gray/black water on Vessel
Model | SWCM | ||||||||||||||||
| 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | 120 | 150 | 200 | 250 | 300 | 400 | |||
| Treated Load | Average Load (L/d) | 1190 | 1540 | 1890 | 2310 | 3080 | 3780 | 4480 | 6020 | 7700 | 9100 | 11200 | 14700 | 18200 | 23100 | 30800 | |
| Peak Load (L/h) | 149 | 193 | 237 | 289 | 385 | 473 | 560 | 753 | 963 | 1138 | 1400 | 1838 | 2275 | 2888 | 3850 | ||
| Organic Load (kgBOD5/d) | 0.595 | 0.77 | 0.945 | 1.155 | 1.54 | 1.89 | 2.24 | 3.01 | 3.85 | 4.55 | 5.6 | 7.35 | 9.1 | 11.55 | 15.4 | ||
| Rated Capacity(P) | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | 120 | 150 | 200 | 250 | 300 | 400 | ||
| Max Capacity(P) | 17 | 22 | 27 | 33 | 44 | 54 | 64 | 86 | 110 | 130 | 160 | 210 | 260 | 330 | 440 | ||
| Electricity | AC380V-50Hz / AC440V-60Hz | ||||||||||||||||
| Power(kw) | 2.25 | 2.5 | 2.5 | 2.5 | 3 | 3 | 3.5 | 4 | 4 | 4 | 6 | 6 | 7 | 9 | 11 | ||
| External Dimensions Length×width×height | 1850 × 1200 × 1400 | 1660 × 1400 × 1550 | 1890 × 1400 × 1560 | 1980 × 1500 × 1650 | 2270 × 1600 × 1700 | 2300 × 1700 × 1820 | 2650 × 1700 × 1830 | 2790 × 1900 × 2050 | 2706 × 2000 × 2200 | 3000 × 2000 × 2200 | 3080 × 2200 × 2300 | 3630 × 2200 × 2350 | 3880 × 2400 × 2570 | 4780 × 2400 × 2600 | 5980 × 2400 × 2600 | ||
| Weight | Dry weight (kg) | 1000 | 1000 | 1100 | 1200 | 1300 | 1450 | 1600 | 1850 | 2200 | 2300 | 2800 | 3000 | 3300 | 3700 | 4200 | |
| Wet weight (kg) | 2283 | 2640 | 2740 | 3500 | 4400 | 5073 | 5270 | 6517 | 8268 | 9166 | 11340 | 13267 | 16538 | 20357 | 25417 | ||
| Discharge Standard | TSS<35mg/L;BOD5<25mg/L;COD<125mg/L;Colichin<100/100ml;PH:6-8.5 | ||||||||||||||||
1.Our Shipyard:Ningbo Zhenhe shipyard, and now Taihang is the branch representative of our yard.
2.Our founding team has experience of more than 15 years in ship building and ship repair with our own engineer and designer.
3.Equipment quality guarantee: Based on shipyard feedback, we built up manufacturer file to ensure the good quality of the products. Also we can send our engineers to help our clients to install and test these exported equipment.
4.We are a second hand ship broker to help you find the satisfied used different kind vessels.
5.We are able to provide the CKD kits and one-stop service based on our laser-cutting machine and purchase ability
6. We have a very professional design and technical team to work out perfect plan for our clients and help to slove out any matters with pre-sale and after-sale.
7.Customer Distribution: Tananzia, Rwanda, India(Mumbai and Kalkatta), Suva, Portugal, Russia, Nertherland, Iceland, Denmark, Malaysia, Mexico.......
