WP-LTR150
1 Year/2000 Working Hours
1 Year
Not Adjustable
Diesel Forklift
Diesel Engine
10T - 18T
Diesel
800mm
3000~5000mm
New
23800kg
15on
26000kg
15ton Rough Terrain Forklift
1200
550/685 mm
Provided
7800mm
Motor, Other, Pump, Gearbox, Engine
1150 mm/1500 mm/1800 mm
3700mm
All Rough Terrain Forklift
Cummins
Provided
3710mm
Secsun
Nude Package, Fix in Container
9700*3040*3350 mm
Fujian, China
Product Description
| Model | LTR150 | ||||
| Fuel type | diesel oil | ||||
| Rated capacity | kg | 15000 | |||
| Load center | mm | 800 | |||
Dimensions | Lift height | mm | 3000 | ||
| Free lift height | mm | 100 | |||
| Fork size | mm | 2400×200×100 | |||
| Shelf Side Shift Distance | Left / Right | mm | 205/205 | ||
| Fork spacing adjustment | Min./Max. | mm | 280/2320 | ||
| Mast tilt angle | /Before / After | deg | 8/10 | ||
| Front overhang | mm | 1380 | |||
Overall dimensions | Length to face of fork | mm | 9700 | ||
| Overall width | mm | 3040 | |||
| Mast lowered height | mm | 3350 | |||
| Mast extended height | mm | 4850 | |||
| Safety rack height | mm | 3700 | |||
| Turning radius | mm | 7800 | |||
| Min.right angle aisle width | mm | 8500 | |||
Performance | / no load/full load | Travel speed | Km/h | 30/28 | |
| Lifting speed | mm/sec | 320/270 | |||
| Max.grade ability | º | ≥21 | |||
| Max.Pull force(full load) | KN | 180 | |||
| Self weight | kg | 23800 | |||
OEM/ODM.
Spare parts
1. Why choose us?
A: We can offer you wide-range products like forklift, loader, excavator, skid steer loader, backhoe loader, road roller, motor
grader, tractor, etc. So we can provide your ONE-STOP SERVICE during purchasing different products with high efficient.
2. What payment terms can we accept?
A: Normally 30% deposit in advance, 70% balance should be paid before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
3. How long is your warranty?
A: One year or 2000 working hours which occurs first.
4. How about our delivery time?
A: Usually it will take 15 - 30 days after receiving your deposit. But for standard products, we always have in stock and can
deliver within 5 days.
5. Can we provide spare parts?
A: Yes, we can provide you the spare parts list if you need, welcome to contact us freely.
