SX5185GSS8J451
24h Online, Professional After-Sales Service Team
6-12 Months
5001 - 10000L
ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Euro 2
8 - 12m
Manual
20T
Diesel
4×2
4 - 6L
New
Optional
Left Hand Drive or Right Hand Drive
Shacman
Nude Packing After Waxed
Heavy Truck
China
870590999
Product Description
Shacman 10, 000~15, 000 Liters/10m3~15m3 Water Truck, Water Spraying Truck, Road Sprinkler Truck
Our main products include full series products of CNHTC(HOWO,STR,Golden Prince,etc.), buses, trailers, including dump truck, tractor truck, concrete mier truck, sprinkler truck, water/Oil tank truck, truck mounted crane, concrete pump truck.etc, low bed semi-trailer, flatbed semi-trailer, bulk cement semi-trailer, skeleton semi-trailer and spare parts for them.
Main Specifications (Configurations can be changed)
Our Factory
SINOTRUK has an annual output of 180, 000 vehicles and 200, 000 engines capacity.
Main products:
Our main Overseas Business Scope
- All types of brand new and used heavy duty truck and light duty trucks
- Special modified vehicle
- All types of semitrailer
- Construction equipment&Machinery
- Pickup, VAN, Bus
- Spare parts- Service & Maintenance
Our shipping and delivery
Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.
FAQ
Our main products include full series products of CNHTC(HOWO,STR,Golden Prince,etc.), buses, trailers, including dump truck, tractor truck, concrete mier truck, sprinkler truck, water/Oil tank truck, truck mounted crane, concrete pump truck.etc, low bed semi-trailer, flatbed semi-trailer, bulk cement semi-trailer, skeleton semi-trailer and spare parts for them.
Main Specifications (Configurations can be changed)
| Chassis model | SX5185GSS8J451 | |||||
| Overall dimensions(mm) | 7820×2500×3030(mm) | |||||
| Wheel base(mm) | 4500 | |||||
| Driving type | 4×2 | |||||
| Total weight(Kg) | 18000 | |||||
| Cab | L3000 cab | |||||
| Number of axes | 2 | |||||
| Tires No. | 6 | |||||
| Steering | Left drive hand | |||||
| Approach/departure angle | 21/9(°) | |||||
| Front /rear overhang(mm) | 1340/1980(mm) | |||||
| Wheel track(front/rear)(mm) | 1960 /1860 | |||||
| Tyre size | 10.00R20 | |||||
| Max driving speed(km/h) | 89 | |||||
| Steering Gear Box Model | 8JS85TE-C+QD40J | |||||
| Engine Model | WP6.210E32 | |||||
| Engine Type | Diesel | |||||
| Engine horse power | 210hp | |||||
| Engine emission | Euro 2 | |||||
| Tank Body | ||||||
| Water Tanker Capcity | 10000L | |||||
| Pump style | Self-priming centrifugal pump | |||||
| Tanker body material | Q235B carbon steel | |||||
| Water Tank Thickness | 4mm | |||||
| Shape of tank | Elliptic | |||||
| Spraying Width | >14 M | |||||
| Water cannon range | ≥28m | |||||
| Suction height | ≥6m | |||||
| Compartment No. | 1(Can be divided according to customer requirements) | |||||
| Baffle | 2 No,4 mm carbon steel | |||||
| Standard Configuration | Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder.Seat Belts,Side Door Lock Mirror, Heavy-duty Air Compressor,Front Shaft Stabilizer,Room Lamp Key Lock Fuel Tank Cap,Bottom Mounted Spare Wheel Carrier, Halogen Headlamps, Radiator Protector. | |||||
| Selective Configuration | Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump,fire pump,fire gun,pesticide plate,cabin gas control operated,Honda pumps,lights,crane,hanging basket,rear spraying device,barrel pesticide spraying device,gasoline pesticide machine,diesel pesticide machine,LED arrow lights. | |||||
| Water pump | Water pump model:80QZB-60/90N | |||||
| Water pump flow rate(L/m): 60m3/h | ||||||
| Head of delivery(m): 90m | ||||||
| Suction head:6.5m | ||||||
| Shaft power:22.5kw | ||||||
Our FactorySINOTRUK has an annual output of 180, 000 vehicles and 200, 000 engines capacity.
Main products:
Our main Overseas Business Scope
- All types of brand new and used heavy duty truck and light duty trucks
- Special modified vehicle
- All types of semitrailer
- Construction equipment&Machinery
- Pickup, VAN, Bus
- Spare parts- Service & Maintenance
Our shipping and delivery
Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.
FAQ| Minimum order quantity? |
| MOQ is 1 unit. |
| Production period? |
| (Truck & trailer) Within 30-55 days since the moment we got your down payment. (Spare Parts) Within 7 days since the moment we got your down payment. Besides in large quantities or imported |
| Payment term? |
| TT: 100% T/T should be paid before delivery (Truck & trailer) 30% T/T as deposit, the balance should be paid before delivery. or L/C. (Spare Parts) large quantities: 50% T/T as deposit, the balance should be paid before delivery, Or LC,Western union |
| Shipping? |
| (Truck & trailer) by container or RoRo/Bulk shipment. (South America, Middle East, Africa, Oceania etc.) by road or railway.(Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laos etc.) (Spare Parts) Air transportation, such as DHL, TNT, UPS, or Fedex. Large value or Large quantity of goods, by sea or LCL |
| After payment |
| We will prepare the goods as soon as the financial notice money arrives.(It takes about two days for the money to arrive, excluding the weekend). We will take photos for you to confirm before the delivery, and then delivery to you |
