The hydraulic winch are consist of a variety of distributors with shuttle valves controlling the brake and single or dual counterbalance valves,hydraulic motor,brake,planetary gearbox,drum, frame and so on. The user only needs to provide a hydraulic power pack and directional valve. Due to the winches fitted with diversified valve block, it not only simplified the hydraulic system, but also improved the reliability of the winches. In addition, the winches feature a high efficiency at start-up and operation, low noise and energy consumption,and have a compact figure and good economic value.
| Model | The First Layer | Reel bottom diameter(mm) | Total displacement(m/r) | Working pressure diff(bar) | Rope diameter(mm) | Rope capacity(m) | Weight(kg) | |
| Pull force(KN) | Rope speed(m/min) | |||||||
| TH05 | 5 | 43 | 176 | 416 | 150 | 6 | 50 | 47 |
| TH10 | 11 | 32 | 176 | 830 | 160 | 8 | 40 | 47 |
| TH15 | 15 | 25 | 176 | 1040 | 150 | 10 | 30 | 47 |
HANGZHOU TAIHANG TECHNOLOGY IMPORT & EXPORT CO.,LTD
- a professional marine equipment supplier, new building and repairsolution provider in beautifulcity Hangzhou,Zhejiang,China.Our company is a comprehensive company of ship design,construction,maintenance and complete set providing of marine equipments.
* Professional technology
* High-quality product quality
* Perfect service system
- We can supply marine lifting equipment, like all kinds of marine electric winch,marine hydraulic winch,marine windlass and crane according to the buyer's requirements.
