| MODEL | UNIT | LK504 | |
| DIMENSIONS OF TRACTOR | TYPE | / | DRIVE TYPE (4×4) |
| kW | kW | 36.8 | |
| DIMENSION (L×W×H) | mm | 3945×1860×2730 | |
| WHEEL BASE | mm | 2110 | |
| MIN.GROUND CLEARANCE | mm | 350 | |
| MINIMUM OPERATING MASS | kg | 2680 | |
| TREAD | mm | FRONT TREAD:1400(1200~1600)ADJUSTABLE REAR TREAD:1400(1300~1600)ADJUSTABLE | |
| MATCHED POWER | CLUTCH TYPE | / | DRY-TYPE,SINGLE-ACTING |
| ENGINE | / | China emission II 4 CYLINDER | |
| RATED SPEED | r/min | 2400 | |
| WORKING PART | GEAR | / | 12F+12R |
| PTO TYPE | / | 8 SPLINE(6 SPLINE OPTIONAL) | |
| PTO RATED POWER | kW | ≥31.3 | |
| PTO SPEED | r/min | 540/720, 540/1000 | |
| HYDRAULIC SYSTEM | THREE POINT Mounting | / | REAR, THREE-POINT MOUNTING, CAT2 |
| HYDRAULIC OUTPUT | / | DOUBLE WAY VALVE | |
| HYDRAULIC ADJUSTMENT MODE | / | FORCED HYDRAULIC SYSTEM, POSITION CONTROL, FLOATING CONTROL | |
| MAX.LIFTING FORCE AT FRAME CENTER | kN | ≥8.9 | |
| TIRE | STANDARD TYRE SIZE (FRONT/ REAR) | / | 8.3-24/14.9-30 |
| OPTIONAL TYRE | 9.5-24/16.9-30 | ||
| 8.3-20/12.4-28 | |||
| OPTIONS | AIR BRAKE | / | OPTIONAL |
| ROLL BAR & CANOPY | / | OPTIONAL | |
| HEATER CABIN | / | OPTIONAL | |
Iron frame package:16 units in a 40 feet HQ (Without cabin).
1 unit in a 40 feet HQ (with cabin).Shandong Ling Ke Industry Group Co., Ltd. is a manufacturing enterprise engaged in R&D, production and sales of high-end non-road machinery and equipment.
It was established in 1999. The total planned area of the group is more than 650ha. It is a key investment attraction of the municipal government, a major provincial project, and a priority project for new and old kinetic energy.
Ling Ke has always adhered to the two-wheel-driven operation strategy of product management and capital operation, and is committed to creating products with the most three core competitiveness of cost, technology and quality, and has successfully built power machinery, harvesting machinery, construction machinery, financial services, The new pattern of coordinated development of five overseas industrial sectors has formed a complete and competitive industrial chain in the industry.
The annual design and production of 150,000 sets (sets) of mechanical equipment products has exceeded 2 billion yuan in sales revenue in 2020 and is expected to break through 5 billion yuan in 2025.
*National High-tech Enterprise Certification
*CE certification
*SGS Certification
*ISO9001 Quality Management System Certification
*ISO14001 Environmental Management System Certification
*ISO45001 Occupational Health and Safety Management System Certification
*AAA Enterprise Credit Rating
We will continue to work hard and strive to create more and greater brilliance.
Q1:Are you manufacturer or trader?
A1:We are manufacturer since 1999.
A2:We have wheel tractors from 25hp to 300hp. As well as wheel tractors, we also have walking tractor from 8-22hp, mini tractor from 12-20hp, farm implements, rice and corn harvesters and engineering machinery.
Q3:What payment methods do you use?
Q4:What shipment term do you accept?
Q5:How are your products packaged when shipping?
Q6:What's the MOQ?
Q7:What's your warranty?
Q8:Can I use my own logo for distribution?
Q9:Is spare parts available?
A10:You can contact our salesman/saleslady to discuss details.
