LK2604 LK3004
7*24 Hour Service
2years
Wheel Tractor
Farm Tractor, Garden Tractor, Lawn Tractor
ISO, CE, EPA, CCC, ISO/TS16949, EEC, XQC
4WD
Euro II
Gas / Diesel
6-10 Years
Large
According to Customer Requirements
New
Shangchai
221kw
2200
4*4
32f+32r
Double Stage
3041-32.48
450mm
Hydraulic Power
3020
2000-2100
5700*2780*3200
Manual Differential Lock
540/65r30 /650/65r42
Rear Category III Suspension
LK
5700*2780*3200
China
87019410
Product Description
Product Description
.Upgraded chassis to tow super-heavy agricultural machinery.
.32F+32Rgears,gear control is more precise.
.Hydraulic electric control system can be installed for hydraulic output valve and three point hitch. Operation is mor convenient.
.Assembling imported Carraro front axle, the body strength is further improved. .Waterproof,soundproof, air-conditioned cab, equipped with reversing camera, making the driving environment more comfortable.
Product Parameters
| DK Series 260-300Hp Tractor |  | ||
| ·Upgraded DK chassis to tow super-heavy agricultural machinery. · 32F + 32R gears, gear control is more precise. · Hydraulic electric control system can be installed for hydraulic output valve and three point hitch. Operation is more convenient. · Assembling imported Carraro front axle, the body strength is further improved. ·Waterproof, soundproof, air-conditioned cab, equipped with reversing camera, making the driving environment more comfortable | |||
| TRACTOR MODEL | LK2604 | LK3004 | |
| ENGINE BRAND | Shangchai | Shangchai | |
| ENGINE MODEL | SC7H260G3 | SC9DK300G3 | |
| ENGINE POWER | 191.5 kw | 221 kw | |
| ENGINE RATED SPEED | 2200 rpm | 2200 rpm | |
| WEIGHT | 9800 kgs | 10000 kgs | |
| WHEEL DRIVE | 4x4 | ||
| GEAR SHIFT | 32F+32R | ||
| CLUTCH TYPE | Double Action | ||
| DRIVING SPEED | 3.41-32.48 km/h | ||
| PTO | 6 Splines, 540/1000 rpm | ||
| GROUND CLEARANCE | 450 mm | ||
| STEERING TYPE | Hydraulic Power | ||
| WHEEL BASE | 3020 mm | ||
| WHEEL TREAD | 2000-2100 mm | ||
| DIMENSION | 5700x2780x3200 mm | ||
| TIRE SIZE | 540/65R30/650/65R42 | ||
| DIFFERENTIAL LOCK | Manual Differential Lock | ||
| THREE POINT HITCH | Rear Category III suspension | ||
| OPTIONAL | Electric Control Hydraulic System | ||
| Front PTO and Front Suspension | |||
| Cabin Window Water Sprayer | |||
| Air Brake System | |||
| 420/85R28/520/85R38 Double Rear Tire | |||
Farm tools display
