SINOTRUK HOWO TRACTOR TRUCK | ||||||
SPECIFICATION | ||||||
Engine | Modal | WD615.69 | WD615.47 | D12,42 | ||
Emission | Euro 2 | Euro3 | Euro 3 | |||
Displacement | 9.726L | 9.726L | 11.596L | |||
Max Torque ( Nm/rpm) | 1350/1100-1600 | 1500/1100-1600 | 1820/1100-1600 | |||
Type | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | |||
Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance. | |||||
Transmission | SINOTRUK HW series 10/12 speed transmission, main and auxiliary transmission structure, main transmission with double countershaft, auxiliary transmission with planetary reducer. HW19712, 12 forward, 2 reverse HW19710, 10 forward, 2 reverse | |||||
Chassis | Three layers frame 8+8+8mm,U-profile parallel ladder frame and reinforced subframe, all cold riveted cross members | |||||
Front Axle | HF9 for heavy truck, rated load of 9t. drum-type | |||||
Rear Axles | HC16 with double reduction, central single reduction plus planetary wheel reduction and with differential lock | |||||
Drive Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | |||||
Fuel Tank | 400 L Aluminum fuel tank with locking fuel cap, fitted to the off side of the chassis | |||||
Steering | ZF power steering, model ZF8118,hydraulic steering with power assistance. | |||||
Braking System | Service brake: dual circuit compressed air brake. Parking brake(emergency brake):spring energy, compressed air operating on rear wheels | |||||
Auxiliary brake: engine exhaust brake | ||||||
Tyres | Standard is 12.00R20, with spare parts radial tyres 315/80R22.5, 295/80R22.5, 12R22.5 tubeless tire is optional | |||||
Electrical System | Operating voltage | 24V,negative grounded | ||||
Starter | 24V.7.5Kw | |||||
Alternator | 3-phase,28V,1500W | |||||
Batteries | 2*12V,165Ah/180Ah | |||||
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | ||||||
Instrument | Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle | |||||
combined indicators of compressed air pressure, coolant temperature, engine oil pressure | ||||||
battery charging | ||||||
Dimensions (mm) | Wheelbase | 3225+1350,3200+1400 | ||||
Front overhang | 1500 | |||||
Rear overhang | 725 | |||||
Approach angle(°) | 16 | |||||
Departure angel(°) | 70 | |||||
Overall (L*W*H) mm | 6800*2496*3835 | |||||
Weight(kg) | Curb weight | 8800 | ||||
Front axle loading capacity | 9000 | |||||
Rear axle loading capacity | 18000/18000 | |||||
Towable Total Mass(kg) | 40000 | |||||
Performance Parameters | Maximum driving speed(km/h) | 90-102 | ||||
Economic Speed(km/h) | 72-82 | |||||
Maximum Gradability(%) | 35 | |||||
Minimum Turning Diameter(m) | 15 | |||||
Consumption(L/100km) | 30-40 | |||||
Cab | HOWO 76 New face cab(one bed, with air conditioner), all-steel forward control, 55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. HW 79 (two bed) HW70(No bed) | |||||
SINOTRUK HOWO 6x4 Tractor Truck
Good Quality Used Sinotruk Howo Tractor Euro5 2021 6*4 10 Wheels 371/375HP Truck Head Tractor Truck for Sale. This product is the proven product, which features reliable structure, great loading capacity, it's suitable for towing all kinds semi trailer which is used in Logistics business,construction site and Mining area, excellent power from 351-450HP, reliable performance. This product can meet the requirements of different road conditions. This product can satisfy your need of long distance highway transportation.If you have tractor truck purchase plan, I could provide you with the best price and comprehensive service.
1. Who are we?
We are based in Shandong Jinan, China, start from 2019,sell to Africa(30.00%),South Asia(20.00%),Southeast Asia(20.00%),Mid East(20.00%),Domestic Market(10.00%). There are total about 11-50 people in our office.2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final inspection before shipment;
3.What can you buy from us?
used dump truck,Tractor,howo Dump truck,Used Trailer,Trailer
4. Why should you buy from us not from other suppliers?
The company is an enterprise specializing in the export service of used commercial vehicles, providing one-stop services such as procurement, preparation, inspection, customs declaration, transportation and destination customs clearance for foreign customs
5. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
