CFSP-592*287*534-S
Online
Air Filter
Multilayer Polyester Synthetic Fiber
Galvanized Iron/Aluminum Alloy
Medium Filter
Air
Dry
Air Filter
20/25/46mm
70
100%Rh
Galvanized Iron Bar
Boxed
592 x 592 x 534mm
Jiangsu
Product Description
Performance parameters:
Features:
1. Compact and lightweight
2. Unique V-shaped design, sewing process, resistance can be reduced by about 20%
3. High quality multi-layer polyester filter material, high dust tolerance
4. A wide range of wind speed, suitable for a variety of occasions
5. A wide range of standard sizes are available
| Nominal size (inch) | Actual size (mm) | Bag number | Surface wind velocity | Initial resistance (Pa) |
| W×H×D | W×H×D | (PCS) | m/s | G4 M5 M6 F7 F8 F9 |
| 24 x 24 x 21 | 592 x 592 x 534 | 8 | 2.5 | 45 50 55 70 95 135 |
| 24 x 24 x 21 | 592 x 592 x 534 | 6 | 2.5 | 60 65 70 95 130 180 |
| 20 x 24 x 21 | 490 x 592 x 534 | 6 | 2.5 | 45 50 55 70 95 135 |
| 12 x 24 x 21 | 287 x 592 x 534 | 4 | 2.5 | 45 50 55 70 95 135 |
| 24 x 24 x 15 | 592 x 592 x 381 | 8 | 2.5 | 65 70 80 105 145 200 |
| 24 x 24 x 15 | 592 x 592 x 381 | 6 | 2.5 | 85 90 105 140 190 235 |
| 20 x 24 x 15 | 490 x 592 x 381 | 6 | 2.5 | 65 70 80 105 145 200 |
| 12 x 24 x 15 | 287 x 592 x 381 | 4 | 2.5 | 65 70 80 105 145 200 |
1. Compact and lightweight
2. Unique V-shaped design, sewing process, resistance can be reduced by about 20%
3. High quality multi-layer polyester filter material, high dust tolerance
4. A wide range of wind speed, suitable for a variety of occasions
5. A wide range of standard sizes are available
