CFGW-592*592*292
Online
Air Filter
Ultrafine Glass Fiber Filter Paper
ABS Engineering Plastic/Galvanized Frame/Aluminum
Medium Filter
Air
Dry
Air Filter
20mm/25mm
70
100%Rh
Boxed
592 x 592 x 292mm
Jiangsu
Product Description
Performance Parameters:
Features:
1. High quality filter material, no partition design, large dust capacity
2. V-frame structure design, long operating life
3. Strong structure, light weight, easy to handle
4. Suitable for variable air volume and turbulent wind speed systems
| Nominal size (inch) | Actual size (mm) | Thickness (mm) | V number | Surface wind velocity | Initial resistance (Pa) |
| W×H | W×H | D | (V) | m/s | M6 F7 F8 F9 |
| 24 x 24 | 592 x 592 | 292 | 4 | 2.5 | 80 90 110 130 |
| 24 x 20 | 592 x 490 | 292 | 4 | 2.5 | 80 90 110 130 |
| 24 x 12 | 592 x 287 | 292 | 4 | 2.5 | 80 90 110 130 |
| 20 x 24 | 490 x 592 | 292 | 3 | 2.5 | 80 90 110 130 |
| 12 x 24 | 287 x 592 | 292 | 2 | 2.5 | 80 90 110 130 |
| 12 x 12 | 287 x 287 | 292 | 1 | 2.5 | 80 90 110 130 |
Features:
1. High quality filter material, no partition design, large dust capacity
2. V-frame structure design, long operating life
3. Strong structure, light weight, easy to handle
4. Suitable for variable air volume and turbulent wind speed systems
