CFCP-610*610*55-H
Online
Air Filter
Ultrafine Glass Fiber Filter Paper
Aluminium Profile
High Efficiency
Air
Dry
Air Filter
Galvanized Paint Mesh/Aluminum Mesh/Stainless Stee
80
100%Rh
EVA/EPDM/PU
Polyurethane Glue
Boxed
55mm
Jiangsu
Product Description
Performance Parameters:
Features:
1. No partition process, large filtration area, low resistance
2. Double-sided protective net for easy installation
3. Strict selection of materials, 100% factory testing, to ensure that products qualified
4. According to EN1822 test, stable performance
5. Long service life
| Nominal size (inch) | Actual size (mm) | Thickness (mm) | Surface wind velocity | Initial resistance (Pa) |
| W×H | W×H | D | m/s | E10 E11 E12 H13 H14 U15 U16 |
| 2 x 1 | 610 x 305 | 55 | 0.45 | 75 85 100 125 135 150 170 |
| 2 x 2 | 610 x 610 | 55 | 0.45 | 75 85 100 125 135 150 170 |
| 4 x 2 | 1170 x 570 | 55 | 0.45 | 75 85 100 125 135 150 170 |
| 4 x 4 | 1170 x 1170 | 55 | 0.45 | 75 85 100 125 135 150 170 |
| 2 x 1 | 610 x 305 | 70 | 0.45 | 60 70 80 105 110 120 140 |
| 2 x 2 | 610 x 610 | 70 | 0.45 | 60 70 80 105 110 120 140 |
| 4 x 2 | 1170 x 570 | 70 | 0.45 | 60 70 80 105 110 120 140 |
| 4 x 4 | 1170 x 1170 | 70 | 0.45 | 60 70 80 105 110 120 140 |
| 2 x 1 | 610 x 305 | 90 | 0.45 | 40 50 60 80 90 100 115 |
| 2 x 2 | 610 x 610 | 90 | 0.45 | 40 50 60 80 90 100 115 |
| 4 x 2 | 1170 x 570 | 90 | 0.45 | 40 50 60 80 90 100 115 |
| 4 x 4 | 1170 x 1170 | 90 | 0.45 | 40 50 60 80 90 100 115 |
Features:
1. No partition process, large filtration area, low resistance
2. Double-sided protective net for easy installation
3. Strict selection of materials, 100% factory testing, to ensure that products qualified
4. According to EN1822 test, stable performance
5. Long service life
