CBD20-490
Powered Pallet Truck
AC Motor
1T - 5T
Electric
500mm
3000~5000mm
New
JAC
Steel
2-Way
Double Faced
JAC
JAC Standard Export Packing
CE/SGS/ISO9001/ISO14001
Hefei, China
8427109000
Product Description
JAC FORKLIFT SERIES:
Warehousing Series: Pallet truck
Product name: Electric pallet truck
Loading Capacity: 1500KG-2000KG
Advantage:
Power steering system
Warehousing Series: Pallet truck
Product name: Electric pallet truck
Loading Capacity: 1500KG-2000KG
Advantage:
Power steering system
Original America-made Curtis controller, Allbright Contractor, AMP connectors, NSK bearings
Vertical drive system, Driving Floating Adjustable system design
Vertical drive system, Driving Floating Adjustable system design
Maintenance free AC motor provides stronger power and enhanced grade ability
USA CURTIS controller
Two magnetic valves,three kinds of descend speed
Two magnetic valves,three kinds of descend speed
Proximity switch ensure safety and energy-saving
Optional fork tilting device
| Model | CBD20-490 | |
| Configuration NO. | 490 | |
| Load capacity | KG | 2000 |
| Load center | mm | 600 |
| wheel base | mm | 1569 |
| operating type | Walkie/Stand on | |
| Wheels | ||
| wheel type | PU | |
| wheel quantity driving wheel/balance wheel/bearing wheel | 1/2/4 | |
| driving wheel size | mm | Φ248*75 |
| balance wheel size | mm | Φ84*80(double wheel) |
| Bearing wheel size | mm | Φ140*60 |
| Dimension | ||
| min.fork lowered height | mm | 85 |
| max.fork lifting height | mm | 205 |
| max.lifting height | mm | 120 |
| overall fork width | mm | 550/600/685 |
| fork length | mm | 1150/1200 |
| fork width | mm | 165 |
| fork thickness | mm | 75 |
| overall length | mm | 2465 |
| overall width | mm | 790 |
| overall height(with handle) | mm | 1170 |
| overall height(without handle) | mm | N/A |
| min.turning radius | mm | 2278 |
| min.aisle width for pallets 800X1200 | mm | 2568 |
| min.aisle width for pallets 1000X1200 | mm | 2589 |
| Performance | ||
| Travel speed laden/unladen | km/h | 10/10 |
| lift speed laden/unladen | mm/s | 20/25 |
| Gradeability laden/unladen | % | 15/10 |
| Electrical configuration | ||
| drive motor | kw | AC 3 |
| lift motor | kw | DC 1.2 |
| steering motor | kw | DC 0.15 |
| battery voltage/capacity | v/ah | 24/280(320 OPTION) |
| brake | electromagnetic/regenerative | |
| controller | CURTIS | |
| Weight | ||
| Battery weight | kg | 288 |
| service weight with battery | kg | 968 |
